MT7628K 580 MHz, 2GB ROM, 8MB RAM, IEEE 802.11b/g/n 2.4 GHz, 100-240 V/0.35 A
2×2 External Antenna with Enhanced Wi-Fi Coverage.
| Performance |
|---|
| Type |
Network repeater |
| Antenna |
|---|
| Antennas quantity |
2 |
| Antenna type |
External |
| Network |
|---|
| Networking standards |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Wi-Fi band |
Single-band (2.4 GHz) |
| Wi-Fi data rate (max) |
300 Mbit/s |
| Channels quantity (EU) |
13 channels |
| Modulation |
PSK |
| Design |
|---|
| Product colour |
Black |
| Housing material |
Plastic |
| Mounting type |
Wall |
| Quantity per pack |
1 pc(s) |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| Input current |
0.35 A |
| Power consumption (typical) |
3.57 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
|---|
| Width |
80 mm |
| Depth |
54 mm |
| Height |
70 mm |
| Features |
|---|
| Internal memory |
8 MB |
| Flash memory |
2 MB |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
