Layer 2, 8 x RJ45, 4 x 802.3at PoE+, Gigabit Ethernet, 99.6 x 163.7 x 31.7 mm
The USW-Lite-8-PoE is a fully managed Layer 2 switch with eight Gigabit Ethernet ports for your RJ45 Ethernet devices. Four ports also offer auto-sensing 802.3at PoE+ that provide up to a total PoE wattage of 52W for UniFi Access Points or other PoE devices.
Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-Lite-8-PoE offers Layer 2 switching protocols and features. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.
| Management features |
|---|
| Switch layer |
L2 |
| Switch type |
Managed |
| Ports & interfaces |
|---|
| Power connector |
DC-in jack |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Network |
|---|
| 10G support |
No |
| Networking standards |
IEEE 802.3at |
| Data transmission |
|---|
| Switching capacity |
8 Gbit/s |
| Design |
|---|
| Wall mountable |
Yes |
| LED indicators |
Yes |
| Product colour |
White |
| Stackable |
No |
| Rack mounting |
No |
| General |
|---|
| Product family |
UniFi |
| Power |
|---|
| Power consumption (typical) |
60 W |
| DC input voltage |
54 V |
| Number of power supply units |
1 |
| Power supply included |
Yes |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) power per port |
30 W |
| Power over Ethernet plus (PoE+) ports quantity |
4 |
| Power over Ethernet (PoE) type supported |
PoE+ |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
-15 - 40 °C |
| Weight & dimensions |
|---|
| Weight |
450 g |
| Height |
31.7 mm |
| Depth |
99.6 mm |
| Width |
163.7 mm |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
