720W, 32 x GbE RJ45, 16 x 1/2.5 GbE RJ45, 4 x 10G SFP+, 224 Gbps, 1.3" touchscreen, SGCC steel, 1U
A 48-port, Layer 3 Etherlighting™ switch with 2.5 GbE and PoE++ output.
| Packaging content |
|---|
| Rack mount kit |
Yes |
| Manual |
Yes |
| Management features |
|---|
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L3 |
| Switch type |
Managed |
| Ports & interfaces |
|---|
| Power connector |
AC-in jack |
| SFP+ module slots quantity |
4 |
| 2.5G Ethernet (copper) ports quantity |
16 |
| Gigabit Ethernet (copper) ports quantity |
32 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
48 |
| Network |
|---|
| Number of VLANs |
1000 |
| Virtual LAN features |
Voice VLAN |
| VLAN support |
Yes |
| Flow control support |
Yes |
| Broadcast storm control |
Yes |
| Rate limiting |
Yes |
| IPv4 routes |
12000 |
| Port mirroring |
Yes |
| 10G support |
No |
| Networking standards |
IEEE 802.1x |
| Data transmission |
|---|
| Packet buffer memory |
2 MB |
| Jumbo frames support |
Yes |
| Static route |
Yes |
| Forwarding rate |
167 Mpps |
| Switching capacity |
224 Gbit/s |
| MAC address table |
32000 entries |
| Security |
|---|
| Loop protection |
Yes |
| IGMP snooping |
Yes |
| DHCP features |
DHCP guarding, DHCP relay, DHCP server, DHCPv6 snooping |
| Design |
|---|
| Display type |
LCM |
| Backlight display |
Yes |
| LED indicators |
System |
| Reset button |
Yes |
| Housing material |
SGCC |
| Product colour |
Grey |
| Form factor |
1U |
| Rack mounting |
Yes |
| General |
|---|
| Product family |
UniFi |
| Technical details |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Power |
|---|
| Power consumption (max) |
820 W |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Redundant power supply (RPS) support |
Yes |
| Power supply included |
Yes |
| Power source |
AC |
| Power over Ethernet (PoE) |
|---|
| Total Power over Ethernet (PoE) budget |
720 W |
| Power over Ethernet (PoE) power per port |
15.4 W |
| Power over Ethernet (PoE) voltage |
57 V |
| Power over Ethernet 4PPoE (PoE++) ports quantity |
16 |
| Power over Ethernet plus (PoE+) ports quantity |
32 |
| Power over Ethernet (PoE) type supported |
PoE+, PoE++ (4PPoE) |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
|---|
| Heat dissipation |
341.2 BTU/h |
| Operating relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
-5 - 40 °C |
| Weight & dimensions |
|---|
| Weight |
6.2 kg |
| Height |
43.7 mm |
| Depth |
399.6 mm |
| Width |
442.4 mm |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Packaging data |
|---|
| Cables included |
Power |
