Quad-core IPQ5322 at 1.5 GHz, DDR4 1 GB, 10 GbE RJ45, 10G SFP+, 2x RP-SMA (Waterproof), GPS (Waterproof), 20W, IPX6, Aluminum alloy, UV-resistant polycarbonate
High-performance dual 5 GHz WiFi 7-based radios with Multi-Link Operation (MLO) technology for enhanced throughput and reliable connectivity.
| Data transmission |
|---|
| Maximum transfer distance |
100000 m |
| Maximum data transfer rate |
5000 Mbit/s |
| Antenna |
|---|
| Antenna connector type |
RP-SMA |
| Antenna type |
2x2 |
| Wireless LAN features |
|---|
| Modulation |
16-QAM, 64-QAM, 256-QAM, 1024-QAM, 4096-QAM, BPSK, QPSK |
| Frequency band |
5.18 - 5.745 GHz |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| Wi-Fi band |
Single-band (5 GHz) |
| Wi-Fi |
Yes |
| Network |
|---|
| Ethernet LAN data rates |
10,100,1000,10000 Mbit/s |
| Ethernet LAN interface type |
10 Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Connectivity technology |
Wired & Wireless |
| Security |
|---|
| Security algorithms |
AES, WPA3-PSK |
| Features |
|---|
| Internal memory |
1000 MB |
| RAM type |
DDR4 |
| Processor family |
ARM Cortex |
| Processor model |
Cortex-A53 |
| Processor frequency |
1500 MHz |
| Processor manufacturer |
ARM |
| Reset button |
Yes |
| International Protection (IP) code |
IPX6 |
| Network Time Protocol (NTP) client |
Yes |
| Power LED |
Yes |
| LED indicators |
GPS, LAN, Power, Signal strength, Status |
| Product colour |
White |
| Mounting type |
Pole |
| Material |
Aluminium, Polycarbonate (PC) |
| Product type |
Network bridge |
| Power |
|---|
| Power over Ethernet (PoE) |
Yes |
| Power consumption (max) |
20 W |
| DC input voltage |
44 - 54 V |
| Power source type |
PoE |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
-40 - 60 °C |
| Certificates |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Weight & dimensions |
|---|
| Weight |
575 g |
| Height |
249.3 mm |
| Depth |
47.6 mm |
| Width |
82 mm |
| General |
|---|
| Product family |
UISP |
| Packaging data |
|---|
| Quantity per pack |
1 pc(s) |
