E7 Audience, WiFi 7, 12-stream, 10 GbE uplink, 465 m² (5,000 ft²), PoE++ 51W
Enterprise-grade indoor access point designed for high-density environments with 12-stream 5 GHz and 6 GHz WiFi 7 performance, a 10 GbE uplink, and a redundant GbE port for high availability.
| Features |
|---|
| Maximum Tx power (6 GHz) |
30 dBmW |
| Maximum Tx power (5 GHz) |
30 dBmW |
| Band steering |
Yes |
| Wireless meshing |
Yes |
| Rate limiting |
Yes |
| VLAN support |
Yes |
| Fast roaming |
Yes |
| Fit AP mode features |
Hotspot 2.0 |
| Spatial streams |
12 |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Number of users |
1500 user(s) |
| Coverage area |
465 m² |
| Networking standards |
IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Ethernet LAN data rates |
10,100,1000,10000 Mbit/s |
| Maximum data transfer rate (6 GHz) |
11500 Mbit/s |
| Maximum data transfer rate (5 GHz) |
8600 Mbit/s |
| Maximum data transfer rate |
11500 Mbit/s |
| 6 GHz |
Yes |
| 5 GHz |
Yes |
| 2.4 GHz |
No |
| Security |
|---|
| Remote Authentication Dial-In User Service (RADIUS) |
Yes |
| Security algorithms |
PPSK |
| Management features |
|---|
| Access point management |
Wi-Fi schedule |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
2 |
| Power |
|---|
| Power consumption (typical) |
51 W |
| DC voltage range |
42.5 - 57 V |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet (PoE) type supported |
PoE++ (4PPoE) |
| Design |
|---|
| LED indicators |
Yes |
| Reset button |
Yes |
| Housing material |
Aluminium, Polycarbonate (PC) |
| Product colour |
White |
| Placement |
Pole, Wall |
| Antenna |
|---|
| Antenna gain level (max) |
15 dBi |
| Antenna direction type |
Directional |
| Antenna type |
Internal |
| Certificates |
|---|
| Compliance certificates |
CE, National Defense Authorization Act (NDAA) |
| Weight & dimensions |
|---|
| Weight |
3.2 kg |
| Height |
239.4 mm |
| Depth |
42.2 mm |
| Width |
474.1 mm |
| Packaging content |
|---|
| Mounting kit |
Yes |
| Quantity per pack |
1 pc(s) |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
5 - 95% |
