8x LAN, WAN, PoE/PoE+, Bluetooth, 4 GB DDR4, 16 GB eMMC, 128 GB SSD
All-in-one router and security gateway with an integrated PoE switch and network video recorder.
The Dream Machine Special Edition (UDM SE) is an enterprise-grade UniFi OS Console capable of helping home and business owners alike seamlessly scale and manage their networks with high-speed, dual-WAN connectivity (10G SFP+ and 2.5GbE RJ45 ports), a Gigabit, PoE switch, and a network video recorder (NVR) with 128 GB of internal storage. Powered by UniFi OS, the UDM SE gives you full control of all your UniFi devices, including access points, Protect cameras, Talk phones, and Access readers. It's also a future-proof console since it will be able to run all upcoming UniFi OS applications. Engineered for end-to-end simplicity, the UDM SE features an integrated Bluetooth radio that streamlines the initial setup and configuration process, which can be completed in minutes with the UniFI Network application (web or mobile).
| Design |
|---|
| LED indicators |
HDD, LAN |
| Mounting type |
Rack mounting |
| Enclosure material |
Aluminum |
| Rack capacity |
1U |
| Product colour |
Stainless steel |
| Performance |
|---|
| Flash memory |
16384 MB |
| Internal memory |
4096 MB |
| Internal memory type |
DDR4 |
| Number of processors installed |
1 |
| Processor frequency |
1700 MHz |
| Built-in processor |
Yes |
| Control display unit |
Yes |
| Network |
|---|
| Bluetooth |
Yes |
| Networking standards |
IEEE 802.3af, IEEE 802.3at |
| Ethernet LAN data rates |
1000 Mbit/s |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
8 |
| WAN connection |
Ethernet (RJ-45) |
| Management features |
|---|
| Reset button |
Yes |
| Power |
|---|
| Power supply |
240 W |
| Power over Ethernet (PoE) |
Yes |
| Input current |
4.4 A |
| Input frequency |
50 - 60 Hz |
| Input voltage |
100 - 240 V |
| Weight & dimensions |
|---|
| Weight |
4.95 kg |
| Width |
442.4 mm |
| Depth |
285.6 mm |
| Height |
43.7 mm |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
-10 - 40 °C |
| Display |
|---|
| Touchscreen |
Yes |
| Display diagonal |
3.3 cm (1.3") |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
