1+ Gbps, 5150 - 5250MHz/5740 - 5850MHz, LTU IC, 200+ km, 128-bit AES
The New Standard for WISP Backhaul Performance
True 1Gbps+ Spectrally Efficient, Noise Resilient PTP Technology Specifically Designed for WISP’s
Complete Custom Hardware for the WISP, right down to the Silicon
Our core communications processing engine surpasses all of the limitations inherent to generic Wi‐Fi chips.
Game-Changing LTU Technology
Spectral Efficiency Comparison of 802.11n, 802.11ac, airFiber Original, and LTU by year.
IP-67 Durability
airFiber 5XHD is Water Resistant and Perfect for any Weather Conditions.
| Features |
|---|
| Transmitting power |
29 dBmW |
| Maximum outdoor range |
200000 m |
| GPS (satellite) |
Yes |
| Modulation |
QAM |
| Channel bandwidth |
100 MHz |
| Frequency band |
5.150 - 5.250 / 5.740 - 5.850 GHz |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Maximum data transfer rate |
1000 Mbit/s |
| 5 GHz |
Yes |
| Security |
|---|
| Security algorithms |
256-bit AES |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
2 |
| Power |
|---|
| Power consumption (max) |
12 W |
| Output current |
1 A |
| Output voltage |
24 V |
| AC input voltage |
20 - 50 V |
| Power over Ethernet (PoE) |
Yes |
| Design |
|---|
| Internal |
No |
| Certification |
FCC |
| International Protection (IP) code |
IP67 |
| Product colour |
White |
| Placement |
Wall |
| Performance |
|---|
| Operating system installed |
AirOS |
| Weight & dimensions |
|---|
| Weight |
350 g |
| Height |
224 mm |
| Depth |
48 mm |
| Width |
82 mm |
| Packaging content |
|---|
| Mounting kit |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-40 - 55 °C |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
