16GB, MLC, Read 90MB/s, Write 60MB/s, 0.76W
Boasting high-speed data transfer rates and extra large storage space, Transcend's industrial CF170 CompactFlash cards are perfect for embedded systems, medical instruments, road surveillance systems, and other industrial applications with demanding performance and capacity requirements. Thanks to their use of StaticDataRefresh and EarlyRetirement technology, the CF170 CF cards are able to correct data errors, maintain data integrity, and extend the lifespan of their flash memory cells.
- Operation Modes: PC Card Memory Mode, PC Card IO Mode and True IDE Mode
- CompactFlash Specification V6.0 compliant
- Built-in advanced ECC and wear-leveling algorithm
- Excellent temperature flexibility, shock and vibration resistant
| Memory |
|---|
| Internal memory type |
MLC |
| Write speed |
60 MB/s |
| Read speed |
90 MB/s |
| Flash card type |
CompactFlash |
| Capacity |
16 GB |
| Features |
|---|
| Certification |
CE, FCC, BSMI |
| Mean time between failures (MTBF) |
1000000 h |
| Protection features |
Heat resistant, Shock resistant |
| Power |
|---|
| Memory voltage |
3.3,5 V |
| Power consumption (read) |
208.4 mA |
| Power consumption (write) |
126.9 mA |
| Operational conditions |
|---|
| Vibration resistance |
20 G |
| Operating shock |
1500 G |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage temperature (T-T) |
-40 - 85 °C |
| Operating temperature (T-T) |
-25 - 85 °C |
| Weight & dimensions |
|---|
| Height |
36.4 mm |
| Depth |
3.3 mm |
| Width |
42.8 mm |
| Packaging data |
|---|
| Quantity per pack |
1 pc(s) |
