300Mbps Wireless N Speed Router,IEE 802.11b/g/n
300Mbps Wireless N Speed - Fast Downloads
TL-WR820N is compatible with IEE 802.11b/g/n and provides a high-speed Wi-Fi. Enjoy speeds of up to 300 Mbps for even your most demanding home networking needs, such as HD streaming, online gaming, and downloading large files.
Strong Signal, Great Coverage
Two powerful 5dBi antennas and 2×2 MIMO enhance wireless transmission to deliver broader wireless coverage with stronger signal intensity.
Smooth Video Streaming
IGMP Proxy/Snooping, Bridge, and Tag VLAN support optimizes IPTV streaming so you can enjoy your favourite movies and shows lag-free.
Guest Network
The Guest Network function provides secure access for guests to use your Wi-Fi network. Share with anyone, without compromising your private network.
Premium Design
An ergonomic shape and sleek texture make for a stylish addition to any room. A hole-punched top plate dissipates heat to ensure long-term functionality and stable operation.
IPv6 Compatible
Compatible with the most recent Internet Protocol version (IPv6) keeps your router future-proof and allows you to enjoy IPv6 services provided by your ISP and visit IPv6 websites.
| WAN connection |
|---|
| 3G/4G USB modem compatibility |
No |
| SIM card slot |
No |
| DSL WAN |
No |
| Ethernet WAN |
Yes |
| Wireless LAN features |
|---|
| WLAN data transfer rate (third band) |
300 Mbit/s |
| WLAN data transfer rate (second band) |
54 Mbit/s |
| WLAN data transfer rate (first band) |
11 Mbit/s |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) |
300 Mbit/s |
| Top Wi-Fi standard |
Wi-Fi 4 (802.11n) |
| Wi-Fi band |
Single-band (2.4 GHz) |
| Network |
|---|
| Static route |
Yes |
| Policy-based routing |
Yes |
| Dynamic DNS (DDNS) |
Yes |
| Port forwarding |
Yes |
| Networking standards |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Cabling technology |
10/100Base-T(X) |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN |
Yes |
| Mobile network |
|---|
| 3G |
No |
| 4G |
No |
| Ports & interfaces |
|---|
| DC-in jack |
Yes |
| Memory card slot(s) |
No |
| USB port |
No |
| Ethernet LAN (RJ-45) ports |
3 |
| Management features |
|---|
| WPS push button |
Yes |
| Reset button |
Yes |
| Web-based management |
Yes |
| Security |
|---|
| DMZ support |
Yes |
| URL filtering |
Yes |
| IP address filtering |
Yes |
| MAC address filtering |
Yes |
| Filtering |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| Guest access |
Yes |
| Firewall |
Yes |
| Security algorithms |
WEP, WPA, WPA2, WPA2-PSK |
| Protocols |
|---|
| Media access protocol |
Access Control, Local Management, Remote Management |
| Universal Plug and Play (UPnP) |
Yes |
| DHCP server |
Yes |
| DHCP client |
Yes |
| Design |
|---|
| LED indicators |
Activity, LAN, WLAN |
| Product colour |
White |
| Product type |
Tabletop router |
| Packaging content |
|---|
| Quick installation guide |
Yes |
| AC adapter included |
Yes |
| Cables included |
LAN (RJ-45) |
| Antenna |
|---|
| Antenna gain level (max) |
5 dBi |
| Antenna design |
External |
| Features |
|---|
| Certification |
CE, RoHS |
| Firmware upgradeable |
Yes |
| Plug and Play |
Yes |
| Power |
|---|
| Output current |
0.6 A |
| Output voltage |
5 V |
| Power source type |
DC |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| System requirements |
|---|
| Mac compatibility |
Yes |
| Linux operating systems supported |
Yes |
| Windows operating systems supported |
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Weight & dimensions |
|---|
| Width |
154 mm |
| Depth |
114 mm |
| Height |
36 mm |
| Packaging data |
|---|
| Number of products included |
1 pc(s) |
