4G LTE, 3x LAN, 1x LAN/WAN, Wi-Fi, 300Mbps at 2.4GHz, IPv4/IPv6
Superfast 4G LTE Speed for Reliable Wi-Fi
The TL-MR150 uses 4G LTE technology to achieve speeds of up to 150Mbps download and 50Mbps upload. It also shares a Wi-Fi network with maximum speed of 300Mbps on 2.4GHz for gaming, streaming, and more.
Design for Maximum Network Coverage
Advanced LTE antennas make efficient and stable connections to every device. Power Amplifier and Low Noise Amplifier boost sending and receiving capabilities, creating a wide-coverage Wi-Fi network for your home.
Plug and Play with a Micro SIM Card
Simply insert your 3G/4G Micro SIM card into the built-in slot, turn on the TL-MR150 and start surfing!
Available WAN Connection Backup
With a fully functional WAN/LAN port, TL-MR150 can work as a router which is compatible with cable, fiber, and DSL modems.
| WAN connection |
|---|
| WAN connection type |
RJ-45 |
| 3G/4G USB modem compatibility |
Yes |
| SIM card slot |
Yes |
| DSL WAN |
Yes |
| Ethernet WAN |
Yes |
| Wireless LAN features |
|---|
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) |
300 Mbit/s |
| Top Wi-Fi standard |
Wi-Fi 4 (802.11n) |
| Wi-Fi band |
Single-band (2.4 GHz) |
| Network |
|---|
| Receiver sensitivity |
11g 54M: -74dBm11n HT20: -71dBm11n HT40: -67dBm |
| Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n) |
20 dBmW |
| VPN support |
PPTP, L2TP, IPSec |
| VPN Passthrough |
Yes |
| Dynamic DNS (DDNS) |
Yes |
| Networking standards |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Cabling technology |
10/100Base-T(X) |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN |
Yes |
| Mobile network |
|---|
| 4G bands supported |
800,900,1800,1900,2100,2300,2500,2600 MHz |
| 3G bands supported |
900,2100 MHz |
| 4G standard |
LTE-TDD & LTE-FDD |
| 3G standards |
DC-HSPA+, HSPA, HSPA+, UMTS |
| 3G |
Yes |
| 4G |
Yes |
| Mobile network generation |
4G |
| Ports & interfaces |
|---|
| DC-in jack |
Yes |
| Memory card slot(s) |
No |
| USB port |
No |
| Ethernet LAN (RJ-45) ports |
4 |
| Management features |
|---|
| WPS push button |
Yes |
| Reset button |
Yes |
| Quality of Service (QoS) support |
Yes |
| Security |
|---|
| DMZ support |
Yes |
| IP address filtering |
Yes |
| MAC address filtering |
Yes |
| DoS attack prevention |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| Guest access |
Yes |
| Access Control List (ACL) |
Yes |
| Firewall |
Yes |
| Security algorithms |
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Protocols |
|---|
| Supported network protocols |
IPv4, IPv6 |
| Universal Plug and Play (UPnP) |
Yes |
| DHCP server |
Yes |
| DHCP client |
Yes |
| Design |
|---|
| On/off switch |
Yes |
| Product colour |
Black |
| Product type |
Tabletop router |
| Packaging content |
|---|
| Quick installation guide |
Yes |
| AC adapter included |
Yes |
| Cables included |
LAN (RJ-45) |
| Antenna |
|---|
| Antennas quantity |
2 |
| Antenna connector type |
N-type |
| Antenna design |
External |
| Features |
|---|
| Certification |
CE, RoHS |
| Power |
|---|
| Output current |
0.85 A |
| Output voltage |
9 V |
| Power source type |
DC |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| System requirements |
|---|
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Windows operating systems supported |
Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Browser supported |
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 |
| Weight & dimensions |
|---|
| Width |
202 mm |
| Depth |
141 mm |
| Height |
33.6 mm |
| Packaging data |
|---|
| Package type |
Box |
