2.4GHz:300Mbps, 2G/3G/4G LTE, VoLTE, 802.11b/g/n, 1 x 10/100Mpbs LAN, 1 x 10/10Mbps LAN/WAN, 1 x Tel Port, 1 x 2FF SIM Card, 350g, White
Wiring free Broadband access wherever you are
With LTE signal coverage for best performance and allows you to receive Internet access without cable and fiber ,it is the ideal choice for remote areas such as rural and suburban ,temporary store,holiday home ,giving devices ability to access to the Internet wherever and whenever the user is located.
High Quality Voice service
Based on the IP Multimedia Subsystem (IMS) network, with specific profiles for control and media planes of voice service on the LTE wireless broadband service.
Share your Wi-Fi up to 32 devices
Thanks to a powerful 880MHz and 28nm processor ,it shares the Wi-Fi up to 32 devicees base on dependable network .
Instantly access a mobile network with a Mini SIM card
Access a mobile network instantly just with an authorized Mini SIM card
| WAN connection |
|---|
| Ethernet WAN |
Yes |
| DSL WAN |
No |
| SIM card slot |
Yes |
| 3G/4G USB modem compatibility |
No |
| WAN connection type |
RJ-45 |
| Wireless LAN features |
|---|
| Wi-Fi band |
Single-band (2.4 GHz) |
| Top Wi-Fi standard |
Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) |
300 Mbit/s |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Cabling technology |
10/100Base-T(X) |
| Networking standards |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Mobile network |
|---|
| Mobile network generation |
4G |
| 4G |
Yes |
| 3G |
Yes |
| 2G standards |
GSM |
| 3G standards |
WCDMA |
| 4G standard |
LTE-TDD & LTE-FDD |
| Short Message Service (SMS) |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
2 |
| USB port |
No |
| RJ-11 ports quantity |
1 |
| Memory card slot(s) |
No |
| DC-in jack |
Yes |
| Management features |
|---|
| Web-based management |
Yes |
| Quality of Service (QoS) support |
Yes |
| Reset button |
Yes |
| WPS push button |
Yes |
| Security |
|---|
| Security algorithms |
WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Firewall |
Yes |
| Guest access |
Yes |
| Schedule access |
Yes |
| Protocols |
|---|
| DHCP client |
No |
| DHCP server |
Yes |
| Design |
|---|
| Product type |
Tabletop router |
| Product colour |
White |
| Wall mountable |
Yes |
| Indication light |
Yes |
| LED indicators |
LAN, LTE, Link, Power, WAN, WLAN |
| On/off switch |
Yes |
| Certificates |
|---|
| Compliance certificates |
CE, RoHS |
| Packaging content |
|---|
| Cables included |
LAN (RJ-45), Phone (RJ-11) |
| AC adapter included |
Yes |
| Quick installation guide |
Yes |
| Antenna |
|---|
| Antenna design |
Internal & external |
| Antennas quantity |
4 |
| Detachable antenna(s) |
Yes |
| Transmit power |
20 dBmW |
| Features |
|---|
| Built-in processor |
Yes |
| Power |
|---|
| Power source type |
AC, DC |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Output voltage |
9 V |
| Output current |
1 A |
| External power adapter |
Yes |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
5 - 90% |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-30 - 70 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Weight |
350 g |
| Height |
185 mm |
| Depth |
69 mm |
| Width |
126 mm |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
