Dual Band Wi-Fi 6 Range Extender
A23 is a Wi-Fi6 range extender designed for large homes,its dual-band concurrent speed is up to 1501 Mbps(5GHz: 1201 Mbps 2.4 GHz: 300 Mbps).Equipped with 2*5dBi high-gain antennas to effectively enhance signal transmission and reception sensitivity.With a Gigabit Ethernet port,A23 can provide wired connections for devices such as set-top boxes,PC,game consoles,and smart TV, making it more flexible to use.It supports AP mode, providing you with more extensive expansion modes.With the intelligent signal indicator and automatic pop-up settings,you can easily find the best place to extend your Wi-Fi coverage and set it up quickly,so that you can enjoy high-speed Wi-Fi 6 immediately.It supports Wi-Fi+ technology,just enjoy a more stable and smoother wireless network in your home.
| Performance |
|---|
| Type |
Network transmitter & receiver |
| Data transfer rate |
1201 Mbit/s |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| WPS push button |
Yes |
| Antenna |
|---|
| Antennas quantity |
2 |
| Antenna gain level (max) |
5 dBi |
| Antenna type |
External |
| Network |
|---|
| Cabling technology |
10/100/1000Base-T(X) |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi |
Yes |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Security algorithms |
WPA2-PSK, WPA3-SAE |
| Design |
|---|
| Reset button |
Yes |
| Certification |
FCC CE SRRC ROSH UCCA |
| Power |
|---|
| Power consumption (typical) |
11 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
|---|
| Width |
72 mm |
| Depth |
123 mm |
| Height |
47.5 mm |
