Business Monitor 27B1U5601H LCD monitor with USB-C docking
This USB-C monitor is for video watching, data transfer and power delivery. The integrated 5MP webcam delivers sharp images, and noise cancelling mic let people hear you fine. Pop-up webcam for quick access and strong security.
| Display |
|---|
| Display diagonal |
68.6 cm (27") |
| Display resolution |
2560 x 1440 pixels |
| Native aspect ratio |
16:9 |
| Display technology |
LCD |
| Touchscreen |
No |
| HD type |
Quad HD |
| Panel type |
IPS |
| LED backlight |
Yes |
| Backlight type |
W-LED |
| Display brightness (typical) |
350 cd/m² |
| Response time |
4 ms |
| Anti-glare screen |
Yes |
| Screen shape |
Flat |
| Contrast ratio (typical) |
1000:1 |
| Contrast ratio (dynamic) |
50000000:1 |
| Dynamic contrast ratio marketing name |
SmartContrast |
| Maximum refresh rate |
75 Hz |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
16.7 million colours |
| Pixel pitch |
0.2331 x 0.2331 mm |
| Pixel density |
109 ppi |
| Horizontal scan range |
30 - 114 kHz |
| Vertical scan range |
48 - 75 Hz |
| Viewable size, horizontal |
59.7 cm |
| Viewable size, vertical |
33.6 cm |
| Display diagonal (metric) |
68.5 cm |
| DDC/CI |
Yes |
| Haze rate |
25% |
| Surface hardness |
3H |
| Colour depth |
8 bit |
| Colour gamut |
89% |
| sRGB coverage (typical) |
101% |
| NTSC coverage (typical) |
89% |
| Display sRGB |
Yes |
| Colour gamut standard |
sRGB, NTSC |
| Display panel size |
27 inch / 68.5 cm |
| Performance |
|---|
| NVIDIA G-SYNC |
No |
| AMD FreeSync |
No |
| Fast charging |
Yes |
| Fast charging technology |
Power Delivery |
| Component video sync |
Separate Sync |
| Flicker-free technology |
Yes |
| Low Blue Light technology |
Yes |
| Compatible operating systems |
DDC/CI, Mac OS X, sRGB, Windows 11 / 10 / 8.1 / 8 / 7 |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Built-in camera |
Yes |
| Number of speakers |
2 |
| RMS rated power |
10 W |
| Megapixel (approx.) |
5 MP |
| Built-in microphone |
Yes |
| Design |
|---|
| Market positioning |
Business |
| Product colour |
Black |
| Front bezel colour |
Black |
| Feet colour |
Black |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| USB hub version |
3.2 Gen 2 (3.1 Gen 2) |
| USB upstream port type |
USB Type-C |
| USB Type-A downstream ports quantity |
4 |
| USB Type-C downstream ports quantity |
1 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB Power Delivery |
Yes |
| USB Power Delivery up to |
100 W |
| HDMI |
Yes |
| HDMI ports quantity |
1 |
| HDMI version |
1.4 |
| DisplayPorts quantity |
1 |
| DisplayPort out quantity |
1 |
| DisplayPort version |
1.4 |
| Headphone out |
Yes |
| HDCP |
Yes |
| HDCP version |
2.2 |
| DisplayPort output |
Yes |
| Ergonomics |
|---|
| VESA mounting |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Height adjustment |
Yes |
| Adjustable height (max) |
15 cm |
| Pivot |
Yes |
| Pivot angle |
-90 - 90° |
| Swivelling |
Yes |
| Swivel angle range |
-180 - 180° |
| Tilt adjustment |
Yes |
| Tilt angle range |
-5 - 30° |
| Picture-in-Picture |
Yes |
| On Screen Display (OSD) |
Yes |
| On Screen Display (OSD) languages |
Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian |
| Plug and Play |
Yes |
| LED indicators |
Operation, Stand-by |
| Power |
|---|
| Energy efficiency class (SDR) |
E |
| Energy efficiency class (HDR) |
Not available |
| Energy consumption (SDR) per 1000 hours |
26 kWh |
| Power consumption (typical) |
21.5 W |
| Power consumption (standby) |
0.4 W |
| Power consumption (off) |
0 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power supply type |
Internal |
| Energy efficiency scale |
A to G |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Operating altitude |
0 - 3658 m |
| Non-operating altitude |
0 - 12192 m |
| Packaging content |
|---|
| Stand included |
Yes |
| Cables included |
AC, HDMI, USB Type-C to USB Type-A, USB Type-C to USB Type-C |
| Manual |
Yes |
| Bundled software |
SmartControl |
| Weight & dimensions |
|---|
| Width (with stand) |
613 mm |
| Depth (with stand) |
225 mm |
| Height (with stand) |
537 mm |
| Weight (with stand) |
7.3 kg |
| Width (without stand) |
613 mm |
| Depth (without stand) |
55 mm |
| Height (without stand) |
366 mm |
| Weight (without stand) |
5.54 kg |
| Packaging data |
|---|
| Package width |
730 mm |
| Package depth |
193 mm |
| Package height |
471 mm |
| Package weight |
10.9 kg |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Sustainability certificates |
ENERGY STAR, TCO |
| Doesn't contain |
Mercury, PVC/BFR |
| General |
|---|
| Product family |
5000 series |
| Recycling data |
|---|
| Post-consumer recycled plastic |
85% |
| Technical details |
|---|
| Native refresh rate |
60 Hz |
| Compliance certificates |
RoHS |
| Other features |
|---|
| HBR3 support |
Yes |
| Picture-by-Picture (PbP) |
Yes |
| Exterior finish type |
Textured |
| Monitor sync input signal |
Separate Sync |
| LowBlue mode |
Yes |
| EasyRead mode |
Yes |
| Light sensor |
Yes |
| Recyclable packaging material |
100% |
| Mean time between failures (MTBF) |
70000 h |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| MultiView |
PIP/PBP mode, 2x devices |
| User controls |
SmartImage, Input, User, Menu, Power On/Off |
| Regulatory Approvals |
CB; CE Mark; FCC Class B; ICES-003; CU-EAC; EAEU RoHS; TUV Ergo; TUV/GS; TUV Eye Comfort certified; MEPS; RCM |
| Picture enhancement |
SmartImage |
| Wake-on-LAN |
Yes |
