8GB (1x8GB), 5600MT/s, 46, 1.1V
SIGNATURE LINE DDR5
Patriot's Signature Line DDR5 memory modules are designed to deliver an immense performance improvement for next generation Intel platforms. Requiring only 1.1V of power, Signature Line DDR5 modules consume less power and emit less heat despite the increased frequency and speed. Enhanced power improvements include an onboard Power Management IC (PMIC), which provides better control of local voltage regulation while delivering increased threshold protection, simultaneous monitoring, intelligent voltage, and power management. The Signature Line DDR5 series includes onboard thermal sensors to monitor and protect against thermal issues and better overall reporting. In addition, the latest on-die ECC (Error-Correcting Code) further enhances the accuracy of data-processing and your overall system's stability.
| Features |
|---|
| Certification |
RoHS |
| Memory voltage |
1.1 V |
| Memory data transfer rate |
5600 MT/s |
| On-Die ECC |
Yes |
| ECC |
No |
| Memory form factor |
262-pin LPCAMM2 |
| Component for |
PC/Server |
| Internal memory type |
DDR5 |
| Memory layout (modules x size) |
1 x 8 GB |
| Internal memory |
8 GB |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 85 °C |
| General |
|---|
| Product family |
Signature Line |
| Weight & dimensions |
|---|
| Weight |
17 g |
| Height |
32 mm |
| Depth |
2 mm |
| Width |
133 mm |
| Packaging data |
|---|
| Package weight |
29 g |
| Package height |
170 mm |
| Package depth |
12 mm |
| Package width |
61 mm |
