2.8”, 320x240, 1GB/8GB, 1.8 GHz, 24 keys, 1D/2D CMOS, BT, GPS, NFC, 4G, WiFi, USB, Android 8.1, 3300 mAh, 158 x 59 x 18.3 mm, 155 g
Equipped with Newland’s 6th generation decoder chip, the MT37 Baiji can scan even damaged or poor quality barcodes with ease and speed.
The special pre-installed DCAPP software allows customizing the MT37 Baiji to any solution you might require.
Light and Portable Data Collector
Made for high-demand operations, the MT37 Baiji provides a lightweight & ergonomic design to reduce fatigue during extended work sessions, and a long-lasting battery to get you through the entire shift without re-charging or switching out devices.
Superior Scanning Capabilities.
MT37 Baiji’s integrated 2D scan engine, equipped with Newland's 6th generation decoder chip, supports both 1D and 2D barcodes. The MT37 Baiji is set up to decode even damaged or poor-quality barcodes with ease and speed.
User-focused Ergonomics.
Made for high-demand operations, the MT37 Baiji renders a lightweight & ergonomic design to reduce fatigue during extended work sessions. The numeric keypad with some additional navigation buttons and a capacitive touch screen provides users with all the input choices they need.
Extended Battery Life.
The MT37 Baiji's 3300 mAh battery lasts up to 10 hours on a single charge. This enables you to get through your entire shift without re-charging or switching out devices.
Customized Android OS.
Built on Android 8.1 Go, the MT37 Baiji offers extended data security features, including Android's application protection and admin management tools.
Excellent Setup.
The MT37 Baiji is equipped with a Quad-Core processor, Android 8.1 Go OS, high-performance Dual-Band Wi-Fi, and Bluetooth 5.0 connection. Its rugged housing can withstand 1.2m drops to concrete.
DCAPP Software.
The MT37 Baiji comes with pre-installed and pre-licensed Newland DCAPP by Sysdev. Newland's DCAPP is a ready-to-use app that allows you to collect, transfer, and export data in a very simple way. With DCAPP, you can quickly start to collect data with 5 included pre-established templates of ready-to-be-used apps. It can then be synchronized with your PC or server to effortlessly export the gathered data.
| Display |
|---|
| Touch technology |
Multi-touch |
| Touchscreen |
Yes |
| Display resolution |
320 x 240 pixels |
| Display diagonal |
7.11 cm (2.8") |
| Memory |
|---|
| RAM capacity |
1 GB |
| Total storage capacity |
8 GB |
| Flash memory |
8 GB |
| Internal memory |
8 GB |
| Processor |
|---|
| Number of cores |
4 |
| Processor frequency |
1.8 GHz |
| Network |
|---|
| Near Field Communication (NFC) |
Yes |
| Data network |
2G, 3G, 4G, LTE, WCDMA |
| Bluetooth Low Energy (BLE) |
Yes |
| Bluetooth version |
5.0 |
| Bluetooth |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| GPS Performance |
|---|
| GPS (satellite) |
Yes |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| Performance |
|---|
| Keyboard layout |
Alphanumeric |
| LED indicators |
Yes |
| Drop proof |
Yes |
| Vibrating alert |
Yes |
| Phone function |
Yes |
| 2D (matrix & stacked) barcodes supported |
Aztec Code, Data Matrix, Dot Code A, MaxiCode, Micro QR Code, PDF417, QR Code |
| Linear (1D) barcodes supported |
Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), ISBN, ISSN, ITF-14, ITF-6, Industrial 2 of 5, MSI, Matrix 2 of 5, Plessey, UPC-A, UPC-E |
| Scanner type |
1D/2D |
| RFID reader |
Yes |
| Barcode reader |
Yes |
| Product colour |
Black |
| Software |
|---|
| Operating system version |
8.1 |
| Operating system installed |
Android |
| Power |
|---|
| Battery voltage |
3.8 V |
| Battery capacity |
3300 mAh |
| Weight & dimensions |
|---|
| Height |
18.3 mm |
| Depth |
59 mm |
| Width |
158 mm |
| Weight |
155 g |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-30 - 60 °C |
| Operating temperature (T-T) |
-20 - 50 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Packaging content |
|---|
| Cables included |
USB Type-C |
