IEEE 802.11b/g/n, 2.400 - 2.4835 GHz, Micro USB 2.0
Equip Your Devices with Wireless Connectivity
300Mbps High Gain Wireless USB Adapter MW300UH.
Two High Gain 5dBi Antennas Leads to Maximized Range
MW300UH has two high-gain external antennas to ensure stronger signal transmission and reception, which helps users to gain a stable Wi-Fi connection across their home.
Desktop Design Greatly Avoids Signal Blocking
The cable makes it easy to find a spot for MW300UH in your workplace. Moreover, compared to the slot-inserted adapters, this design allow you to put it nearer to the router, in which way it can receive stronger signals.
Easy Setup
A friendly user interface on a CD for simple installation.
Operating System
Compatible with Windows 10/8.1/8/7/XP.
| Ports & interfaces |
|---|
| Connectivity technology |
Wired & Wireless |
| Host interface |
USB |
| Interface |
WLAN |
| USB version |
2.0 |
| Network |
|---|
| Maximum data transfer rate |
300 Mbit/s |
| Networking standards |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi |
Yes |
| Wi-Fi band |
Single-band (2.4 GHz) |
| Top Wi-Fi standard |
Wi-Fi 4 (802.11n) |
| Frequency range |
2.4 - 2.4835 GHz |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rates supported |
11,54,300 Mbit/s |
| Security algorithms |
WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Design |
|---|
| Internal |
No |
| Component for |
PC/Laptop |
| Product colour |
White |
| Antenna design |
External |
| Antenna |
Yes |
| Certification |
CE |
| System requirements |
|---|
| Windows operating systems supported |
Windows 10, Windows 10 x64, Windows 7, Windows 7 x64, Windows 8, Windows 8 x64, Windows 8.1, Windows 8.1 x64, Windows XP |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
|---|
| Width |
113.2 mm |
| Depth |
100.5 mm |
| Height |
201.1 mm |
| Packaging data |
|---|
| Package width |
282.5 mm |
| Package depth |
134.5 mm |
| Package height |
41.5 mm |
| Package weight |
220 g |
| Packaging content |
|---|
| Cables included |
USB |
| Technical details |
|---|
| Compliance certificates |
RoHS |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
| Other features |
|---|
| Gain |
5 dBi |
| Antennas quantity |
2 |
