Dual-band, 2.4 GHz, 5 GHz, IEEE 802.11ac/n/a/b/g
Non-Stop Entertainment with Dual-Band Wi-Fi
Complying with the powerful 802.11ac standard, AC10 delivers blazing-fast Wi-Fi speeds up to 1200 Mbps, which is 3× faster than the speed of the previous 802.11n standard. Choose the 300 Mbps (2.4 GHz) for internet surfing, email, and social media or 867 Mbps (5 GHz) for bandwidth-intensive tasks like HD streaming and gaming.
Broader Coverage
Four external 5dBi antennas powered with advanced antenna technology provide users with larger wireless coverage throughout your home or office. With the combination of Beamforming Technology, the AC10 can detect the location of your connected devices and concentrate wireless signal strength towards them, making your connection more stable.
MU-MIMO Technology
With MU-MIMO, AC10 communicates with multiple devices at the same time to allow connected devices to achieve faster speeds than standard AC routers, increasing overall network throughput.
Easy Installation
With no need for complicated configuration, you can simply follow the step-by-step instructions on the intuitive webpage to set up your AC10 in minutes.
Ready for Smooth IPTV
IGMP Proxy/Snooping, Bridge, and Tag VLAN technology allow your streaming activities to pass through fast LAN ports, optimizing Hi-Resolution videos.
| WAN connection |
|---|
| Ethernet WAN |
Yes |
| DSL WAN |
No |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| Wireless LAN features |
|---|
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) |
867 Mbit/s |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (first band) |
300 Mbit/s |
| WLAN data transfer rate (second band) |
867 Mbit/s |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Mobile network |
|---|
| 4G |
No |
| 3G |
No |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Management features |
|---|
| Reset button |
Yes |
| WPS push button |
Yes |
| MU-MIMO technology |
Yes |
| Security |
|---|
| Security algorithms |
WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Design |
|---|
| Product type |
Tabletop router |
| Product colour |
White |
| Antenna |
|---|
| Antenna design |
External |
| Antenna gain level (max) |
5 dBi |
| Antennas quantity |
4 |
| Power |
|---|
| Power source type |
AC |
| Output voltage |
9 V |
| Output current |
0.85 A |
