Intel Xeon Silver 4509Y (22.5MB Cache, 2.6GHz), 32GB DDR5-SDRAM, LAN (Broadcom 57416), 9350-8i, 1100W, No OS
The Lenovo ThinkSystem ST650 V3 is an ideal 2-socket 4U tower server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The ST650 V3 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC..
This product guide provides essential pre-sales information to understand the ThinkSystem ST650 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the ST650 V3 and consider its use in IT solutions.
| Processor |
|---|
| Processor manufacturer |
Intel |
| Processor family |
Intel Xeon Silver |
| Processor model |
4509Y |
| Processor frequency |
2.6 GHz |
| Processor boost frequency |
4.1 GHz |
| Processor cores |
8 |
| Processor cache |
22.5 MB |
| Number of processors installed |
1 |
| Memory |
|---|
| Internal memory |
32 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory layout (slots x size) |
1 x 32 GB |
| ECC |
Yes |
| Maximum internal memory |
4 TB |
| Storage |
|---|
| Maximum storage capacity |
320 TB |
| RAID support |
Yes |
| RAID levels |
0, 1, 10, JBOD |
| Supported RAID controllers |
9350-8i |
| Hot-swap |
Yes |
| Internal drive bays |
8 |
| Optical drive type |
No |
| Network |
|---|
| Ethernet interface type |
10 Gigabit Ethernet |
| Cabling technology |
10/100/1000Base-T(X) |
| LAN controller |
Broadcom 57416 |
| Ethernet LAN |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
2 |
| USB 2.0 ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
5 |
| Serial ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
| Design |
|---|
| Chassis type |
Tower |
| Redundant fans support |
Yes |
| Performance |
|---|
| Performance management |
XClarity Controller Platinum |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Software |
|---|
| Operating system installed |
No |
| Compatible operating systems |
Microsoft Windows Server 2019Microsoft Windows Server 2022Red Hat Enterprise Linux 8.6Red Hat Enterprise Linux 8.7Red Hat Enterprise Linux 9.0Red Hat Enterprise Linux 9.1SUSE Linux Enterprise Server 15 SP4SUSE Linux Enterprise Server 15 Xen SP4Ubuntu 22.04 LTS 64-bitVMware ESXi 7.0 U3VMware ESXi 8.0 U1 |
| Power |
|---|
| Redundant power supply (RPS) support |
Yes |
| Power supply |
1100 W |
| Number of redundant power supplies installed |
1 |
| Power supply input frequency |
50 - 60 Hz |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 45 °C |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
8 - 90% |
| Storage relative humidity (H-H) |
8 - 90% |
| Operating altitude |
0 - 3050 m |
| General |
|---|
| Product family |
ThinkSystem |
| Weight & dimensions |
|---|
| Width |
175 mm |
| Height |
462 mm |
| Depth |
734 mm |
| Weight |
39.1 kg |
