Intel Xeon Silver 4514Y (30MB Cache, 2GHz), 32GB DDR5-SDRAM (5600MHz), 940-8i, 1100W
The Lenovo ThinkSystem SR650 V3 is an ideal 2-socket 2U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR650 V3 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
This product guide provides essential pre-sales information to understand the ThinkSystem SR650 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR650 V3 and consider its use in IT solutions.
| Processor |
|---|
| Maximum number of SMP processors |
2 |
| Number of processors installed |
1 |
| Processor cache |
30 MB |
| Processor cores |
16 |
| Processor boost frequency |
3.4 GHz |
| Processor frequency |
2 GHz |
| Processor model |
4514Y |
| Processor family |
Intel Xeon Silver |
| Processor manufacturer |
Intel |
| Memory |
|---|
| Maximum internal memory |
8.19 TB |
| Memory slots |
32x DIMM |
| ECC |
Yes |
| Memory layout (slots x size) |
1 x 32 GB |
| Memory clock speed |
5600 MHz |
| Internal memory type |
DDR5-SDRAM |
| Internal memory |
32 GB |
| Storage |
|---|
| Supported storage drive interfaces |
SAS |
| Optical drive type |
No |
| Internal drive bays |
8 |
| Hot-swap |
Yes |
| Supported RAID controllers |
940-8i |
| RAID support |
Yes |
| Graphics |
|---|
| Maximum graphics card memory |
16 MB |
| On-board graphics card |
Yes |
| Ports & interfaces |
|---|
| VGA (D-Sub) ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| USB 2.0 ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| Design |
|---|
| Chassis type |
Rack (2U) |
| Performance |
|---|
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Performance management |
XClarity Controller Platinum |
| Software |
|---|
| Compatible operating systems |
Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Ubuntu Server |
| Power |
|---|
| Power supply |
1100 W |
| Redundant power supply (RPS) support |
Yes |
| Certificates |
|---|
| 80 PLUS certification |
80 PLUS Titanium |
| General |
|---|
| Product family |
ThinkSystem |
| Weight & dimensions |
|---|
| Depth |
766 mm |
| Height |
87 mm |
| Width |
445 mm |
| Technical details |
|---|
| 2.5" HDD support |
8 |
