Intel Core i5-14600K processor 24 MB Smart Cache Box

Boxed Intel Core i5 processor 14600K (24M Cache, up to 5.30 GHz) FC-LGA16A

Intel 14th Gen processors, with an increased core count, continue to use Intel's performance hybrid design to optimise your gaming, content production, and productivity. Take advantage of industry-leading bandwidth of up to 16 PCIe 5.0 lanes and DDR5 memory speeds of up to 5600 MT/s. A robust suite of tuning and overclocking tools to boost your CPU performance. Enjoy your favourite experiences on up to four simultaneous 4K@60Hz displays or up to eight simultaneous 8K@60Hz HDR video displays with dynamic noise suppression. Support for the Intel® 700 series chipsets, as well as backward compatibility with the Intel® 600 series chipsets, give you access to the functionality you require for every task. The 14th Gen Intel® CoreTM desktop CPUs give the next level of revolutionary performance, whether you are working, streaming, gaming, or creating.

The 14th Gen Intel® Core™ desktop processors deliver the next generation of breakthrough core performance. Intel® Turbo Boost Max Technology 3.0 further strengthens lightly threaded performance by identifying the best-performing performance cores. Meanwhile, additional E-cores enable an increase in Intel® Smart Cache (L3) for more efficient processing of larger data sets and better performance. The P-core and E-core L2 caches have also increased compared to the previous generation of Intel® processors, minimising the amount of time spent swapping data between cache and memory to speed up your workflow. Unleash the power of next-level performance with the 14th Gen Intel® Core™ desktop processor advantage.

FEATURES:

• 14 Cores


• 20 Threads


• Max Turbo Frequency of up to 5.3GHz


• 24MB Intel® Smart Cache


• Support for DDR4 and DDR5 memory


• Built for serious gaming


• Best overclocking experience


• Smart solutions for enthusiasts and creators

SPECIFICATIONS:

• Essentials:


• Product Collection: 14th Generation Intel® Core™ i5 Processors


• Code Name: Products formerly Raptor Lake


• Vertical Segment: Desktop


• Processor Number: i5-14600K


• CPU Specifications:


• Total Cores: 14


• # of Performance-cores: 6


• # of Efficient-cores: 8


• Total Threads: 20


• Max Turbo Frequency: 5.3 GHz


• Performance-core Max Turbo Frequency: 5.3 GHz


• Efficient-core Max Turbo Frequency: 4 GHz


• Performance-core Base Frequency: 3.50 GHz


• Efficient-core Base Frequency: 2.60 GHz


• Cache: 24 MB Intel® Smart Cache


• Total L2 Cache: 20 MB


• Processor Base Power: 125 W


• Maximum Turbo Power: 181 W


• GPU Specifications:


• Processor Graphics: Intel® UHD Graphics 770


• Graphics Base Frequency: 300 MHz


• Graphics Max Dynamic Frequency: 1.55 GHz


• Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1


• Execution Units: 32


• Max Resolution (HDMI): 4096 x 2160 @ 60Hz


• Max Resolution (DP): 7680 x 4320 @ 60Hz


• Max Resolution (eDP - Integrated Flat Panel): 5120 x 3200 @ 120Hz


• DirectX* Support: 12


• OpenGL* Support: 4.5


• OpenCL* Support: 3.0


• Multi-Format Codec Engines: 2


• Multi-Format Codec Engines: Yes


• Intel® Clear Video HD Technology: Yes# of Displays Supported: 4


• Device ID: 0xA780


• Memory Specifications:


• Max Memory Size (dependent on memory type): 192 GB


• Memory Types: Up to DDR5 5600 MT/s, Up to DDR4 3200 MT/s


• Max # of Memory Channels: 2


• Max Memory Bandwidth: 89.6 GB/s


• Expansion Options:


• Direct Media Interface (DMI) Revision: 4.0


• Max # of DMI Lanes: 8


• Scalability: 1S Only


• PCI Express Revision: 5.0 and 4.0


• PCI Express Configurations: Up to 1×16+4, 2×8+4


• Max # of PCI Express Lanes: 20


• Advanced Features:


• Intel® Gaussian & Neural Accelerator: 3.0


• Intel® Thread Director: Yes


• Intel® Deep Learning Boost (Intel® DL Boost): Yes


• Intel® Speed Shift Technology: Yes


• Intel® Turbo Boost Technology: 2.0


• Intel® Hyper-Threading Technology: Yes


• Intel® 64: Yes


• Instruction Set: 64-bit


• Instruction Set Extensions: Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2


• Idle States: Yes


• Enhanced Intel SpeedStep® Technology: Yes


• Thermal Monitoring Technologies: Yes


• Intel® Volume Management Device (VMD): Yes


• Security & Reliability


• Intel® Standard Manageability (ISM): Yes


• Intel® Control-Flow Enforcement Technology: Yes


• Intel® AES New Instructions: Yes


• Secure Key: Yes


• Intel® OS Guard: Yes


• Execute Disable Bit: Yes


• Intel® Boot Guard: Yes


• Mode-based Execute Control (MBEC): Yes


• Intel® Virtualization Technology (VT-x): Yes


• Intel® Virtualization Technology for Directed I/O (VT-d): Yes


• Intel® VT-x with Extended Page Tables (EPT): Yes

WHAT’S IN THE BOX:

• Intel 14th Gen Core i5-14600K LGA1700 3.5GHz 14-Core CPU x1

Processor
Processor ARK ID	236799
Processor codename	Raptor Lake
Memory bandwidth supported by processor (max)	89.6 GB/s
Maximum number of DMI lanes	8
Stepping	B0
Processor base power	125 W
Maximum turbo power	181 W
Processor cache type	Smart Cache
Processor cache	24 MB
Efficient-core base frequency	2.6 GHz
Efficient-core boost frequency	4 GHz
Performance-core base frequency	3.5 GHz
Performance-core boost frequency	5.3 GHz
Processor boost frequency	5.3 GHz
Efficient cores	8
Performance cores	6
Processor operating modes	64-bit
Processor threads	20
Cooler included	No
Processor socket	LGA 1700
Processor cores	14
Processor model	i5-14600K
Processor generation	Intel® Core™ i5 (14th gen)
Processor family	Intel® Core™ i5
Processor manufacturer	Intel

Memory
Memory bandwidth (max)	89.6 GB/s
Non-ECC	Yes
ECC	Yes
Memory channels	Dual-channel
Memory types supported by processor	DDR4-SDRAM, DDR5-SDRAM
Maximum internal memory supported by processor	192 GB

Graphics
Multi-Format Codec Engines	2
Number of execution units	32
Discrete graphics card model	Not available
On-board graphics card ID	0xA780
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)	60 Hz
On-board graphics card maximum resolution (DisplayPort)	7680 x 4320 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI)	4096 x 2160 pixels
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.5
Number of displays supported (on-board graphics)	4
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	1550 MHz
On-board graphics card outputs supported	Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card model	Intel UHD Graphics 770
On-board graphics card	Yes
Discrete graphics card	No

Features
Commodity Classification Automated Tracking System (CCATS)	740.17B1
Export Control Classification Number (ECCN)	5A992C
Thermal solution specification	PCG 2020A
Direct Media Interface (DMI) Revision	4.0
Scalability	1S
Embedded options available	No
CPU configuration (max)	1
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
PCI Express configurations	1x16+1x4, 2x8+1x4
PCI Express slots version	4.0, 5.0
Maximum number of PCI Express lanes	20
Use conditions	Workstation, PC/Client/Tablet
Market segment	Desktop
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes

Processor special features
Mode-based Execute Control (MBE)	Yes
Intel® Standard Manageability (ISM)	Yes
Intel® OS Guard	Yes
Intel® Boot Guard	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel 64	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Secure Key	Yes
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Intel® Volume Management Device (VMD)	Yes
Intel® Thread Director	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	2.0
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel® Speed Shift Technology	Yes

Operational conditions
Tjunction	100 °C

General
Product family	Core
Product series	i5

Logistics data
Harmonized System (HS) code	8542310001

Packaging data
Package type	Box

Technical details
Launch date	Q4'23
Status	Launched
OpenCL version	3.0

Weight & dimensions
Processor package size	45 x 37.5 mm

Other features
Graphics output	eDP 1.4b, DP 1.4a, HDMI 2.1
Maximum internal memory	192 GB
L2 cache	20480 KB
