1 Gbps, 0.744 Mpps, 4x RJ-45 PoE, 1x RJ-45, 105x27.6x83.1 mm
| Management features |
|---|
| System event log |
Yes |
| Web-based management |
Yes |
| Switch type |
Managed |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports type |
Fast Ethernet (10/100) |
| Basic switching RJ-45 Ethernet ports quantity |
5 |
| Network |
|---|
| Number of VLANs |
4094 |
| VLAN support |
Yes |
| Link aggregation |
Yes |
| Full duplex |
Yes |
| 10G support |
No |
| Networking standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Data transmission |
|---|
| Packet buffer memory |
0.768 MB |
| Store-and-forward |
Yes |
| Forwarding rate |
0.744 Mpps |
| Switching capacity |
1 Gbit/s |
| MAC address table |
2000 entries |
| Design |
|---|
| Housing material |
Metal |
| Product colour |
Blue |
| Power |
|---|
| Power consumption (max) |
65 W |
| Input current |
1.2 A |
| DC input voltage |
54 V |
| Power source |
DC |
| Power over Ethernet (PoE) |
|---|
| Total Power over Ethernet (PoE) budget |
60 W |
| Power over Ethernet (PoE) power per port |
30 W |
| Power over Ethernet (PoE) ports quantity |
4 |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
5 - 95% |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage temperature (T-T) |
-40 - 85 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Weight |
260 g |
| Height |
27.6 mm |
| Depth |
83.1 mm |
| Width |
121 mm |
| Packaging data |
|---|
| Package weight |
750 g |
