Dual 2K+, 1/3” CMOS, 2560 × 1440, 2.8 mm, F1.6, PT, 6 mm, 3D DNR, DWDR, microSD, Wi-Fi, RJ45, USB Type-C, DC 5V / 2A, 270 g
H7c Dual 2K⁺ & 2K⁺
Dual-Lens Pan & Tilt Wi-Fi Camera
Broader and smarter protection with dual lenses
Experience unparalleled indoor vision with the EZVIZ H7c Dual. Using two powerful lenses to ensures comprehensive coverage from top to bottom, the camera provides whole-room protection like never before. Equipped with human motion detection, two-way calling, and crystal-clear day/night vision, it keeps you connected to your home from anywhere, and doubles up your sense of safety with much more flexible features.
Dual lenses. Double protection.
With EZVIZ’s unique dual-lens technology, the H7c Dual provides next-level protection that’s usually achieved through a multi-camera setup. It uses a fixed lens and a main pan-and-tilt lens at the same time – the duo works independently or together in a way that is much smarter than your ordinary camera.
01 See much more for whole-home protection
The H7c Dual captures information that’s more than double of your old home camera. It uses a motorized pan and tilt camera to monitor a large interior space with almost no blind spots, and ensure that you always keep the key area under continuous watch with a fixed view, too.
02 Work together for a single detection task
The two lenses respond to each other to provide the protection that makes it much more difficult for anyone to move out of sight. When a person enters the zone watched by the fixed lens, the PT lens will automatically rotate to such viewing angle to lock on the person, follow to record the entire event, and send notifications with video footages.
03 Big picture and small details both matter
The camera allows you to understand the whole picture while paying attention to the important details. Both wide angle and close-up views are displayed simultaneously on your EZVIZ App. Tap on a specific area in the wide-angle viewing box so that a close-up shot will render much more details for you to double check.
Smarter detection for activities you care about
A lot of activities go on inside your home, but you don’t want to get constantly alerted when your curtains flutter in the wind. The H7c Dual is smart enough to notice human activities in particular and can capture sudden sound changes in the environment – all without additional fees to unlock.
Hands-free and worry-free, with customized auto patrols
On set time intervals, the PT lens can automatically complete check-ups to eliminate blind spots. You can customize patrol routes flexibly for tailored focuses, or simply ask it to complete a full-circle horizontal spin.
Love continues, regardless of distance
Staying connected with your family is always a necessity. A simple tap on the camera is all it takes for your children or elderly parents to reach you.
Overnight protection in vivid colors
The H7c Dual uses starlight lenses to render high-quality colorful images even in low light conditions. Furthermore, it uses a built-in spotlight to deliver color night vision in complete darkness.
When the smart night vision mode is activated, it will automatically switch its view from black-and-white to full-color upon motion detection.
| Performance |
| Antenna gain level (max) |
3.18 dBi |
| Remote viewing |
Yes |
| Day/night mode |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| Connectivity technology |
Wired & Wireless |
| Placement supported |
Indoor |
| Type |
IP security camera |
| Design |
| Product colour |
White |
| Mounting type |
Ceiling/Desk |
| Camera |
| Lens viewing angle, diagonal |
108° |
| Lens viewing angle, vertical |
50° |
| Lens viewing angle, horizontal |
92° |
| Camera tilt control |
Yes |
| Camera pan control |
Yes |
| Panoramic camera |
| Fixed focal length (panoramic camera) |
6 mm |
| Maximum aperture number (panoramic camera) |
1.6 |
| Viewing angle, vertical (panoramic camera) |
28° |
| Viewing angle, horizontal (panoramic camera) |
51° |
| Optical sensor size (panoramic camera) |
25.4 / 3 mm (1 / 3") |
| Number of sensors (panoramic camera) |
1 |
| Sensor type (panoramic camera) |
CMOS |
| Image sensor |
| Progressive scan |
Yes |
| Optical sensor size |
25.4 / 3 mm (1 / 3") |
| Number of sensors |
1 |
| Sensor type |
CMOS |
| Lens system |
| Fixed focal length |
2.8 mm |
| Number of lenses |
1 |
| Night vision |
| Night vision distance |
10 m |
| Night vision |
Yes |
| Video |
| Digital Wide Dynamic Range (DWDR) |
Yes |
| Noise reduction technology |
3D noise reduction |
| Noise reduction |
Yes |
| Frame rate |
30 fps |
| Video recording |
Yes |
| Supported video modes |
1440p |
| Supported graphics resolutions |
2560 x 1440 |
| Video compression formats |
H.264, H.265 |
| Video formats supported |
H.264, H.265 |
| Maximum resolution |
2560 x 1440 pixels |
| Network |
| Frequency band |
2.4 - 5.25 GHz |
| Channel bandwidth |
80 MHz |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Ethernet interface type |
Fast Ethernet |
| Bluetooth |
No |
| Wi-Fi |
Yes |
| Ethernet LAN |
Yes |
| Storage |
| Maximum memory card size |
512 GB |
| Compatible memory cards |
MicroSD (TransFlash) |
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Ports & interfaces |
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
| Privacy protection |
Yes |
| Security algorithms |
WPA-PSK, WPA2-PSK, WPA3-Personal |
| Video motion detection |
Yes |
| Management features |
| Cloud services supported |
EZVIZ Cloud |
| Power |
| DC output current |
2 A |
| DC output voltage |
5 |
| Power consumption (max) |
8 W |
| Power source type |
DC |
| Operational conditions |
| Operating relative humidity (H-H) |
0 - 95% |
| Operating temperature (T-T) |
-10 - 45 °C |
| Weight & dimensions |
| Weight |
270 g |
| Height |
131.5 mm |
| Depth |
88 mm |
| Width |
88 mm |
| Sustainability |
| Compliance certificates |
CE, REACH, RoHS, UKCA, UL, WEEE |
| Packaging data |
| Package weight |
499 g |
| Package height |
105 mm |
| Package depth |
105 mm |
| Package width |
200 mm |
| Packaging content |
| Quick start guide |
Yes |
| AC adapter included |
Yes |
| Drilling template included |
Yes |
| Screws included |
Yes |
| Mounting brackets included |
Yes |
| Cables included |
USB |
| Number of cameras |
1 |
| Other features |
| Noise detection |
Yes |
| Technical details |
| Lens mount interface |
M12 |
