TM-m30III standard model
Ultra-compact receipt printer (standard)
Based on a stylish and ultra-compact design, and with a host of advanced features, the TM-m30III is a perfect combination of mobility, connectivity, reliability and ease-of-use. Providing cost-effective and reliable receipt printing in any environment where space is an issue, it’s designed to meet the needs of a wide range of growing businesses.
Space-efficient , robust and reliable
With an all-new, highly compact, super-sleek design, which reflects today’s demand for a clean and modern aesthetic, the TM-m30III is also robust and reliable, with a range of connectivity options.
Easy connectivity and increased power delivery
Including a USB Type-C PD (Power Delivery) tablet port, now able to supply up to 18W of power to the connected device, the TM-m30III works with most smart devices, and also offers 20Mbps network tethering, which allows the wired network connection to the printer to be shared. A Wi-Fi and Bluetooth option is also available (See TM-m30III Wireless version).
Built for tough environments
Offering protection against the harmful ingress of liquids to IPX2 standards, the TM-m30III has also been designed with easy cleaning in mind, and is externally treated with an ISO22196-certified antibacterial material, making it ideal for challenging environments such as kitchens.
Easy, reliable code scanning
The TM-m30III includes superior de-curl functionality, able to produce flattened receipts with no reduction in print speed. This is particularly useful in applications where code-scanning is important, such as event ticketing, or for producing documents that require a signature.
Boosts speed and efficiency
Offering reliable paper roll near-end detection, which operates with the printer oriented for either front or top paper exit positions, the TM-m30III is ideal for semi-attended applications, such as kiosks or self-checkout, where prompt paper replacement avoids unnecessary downtime.
Easy set-up, excellent support
The printer is supplied with a “quick start” sheet that offers a simple and effective setup guide, while scannable QR-codes link to videos that cover all processes, from unpacking to power on, as well as basic configuration tasks. Expert Epson support is available for iOS, Android and Windows.
| Printing |
|---|
| Print technology |
Thermal |
| Type |
POS printer |
| Colour |
No |
| Maximum resolution |
203 x 203 DPI |
| Print speed |
300 mm/sec |
| Print speed (receipt) |
300 mm/sec |
| Printing characters |
Graphic, Barcode, 2D barcode, Text |
| Paper handling |
|---|
| Roll dimensions |
Roll 57mm, Roll 80mm |
| Supported paper width |
58 - 80 mm |
| Ports & interfaces |
|---|
| Connectivity technology |
Wired |
| USB port |
Yes |
| Near Field Communication (NFC) |
Yes |
| Interface |
USB 2.0-A, USB Type-C, Ethernet interface (100 Base-TX / 10 Base-T), Micro SD Card Slot, USB 2.0 Type B (Service Only), Wireless LAN IEEE 802.11a/b/g/n/ac (optional), Drawer kick-out, Wi-Fi Direct (optional), Near Field Communication (NFC) |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Features |
|---|
| Built-in barcodes |
Code 128 (A/B/C), CODABAR (NW-7), UPC-E, UPC-A, GS1 DataBar, EAN8, GS1-128, EAN13, Code 39, Data Matrix, Code 93, ITF, MaxiCode, PDF417 |
| Sound pressure level (printing) |
53 dB |
| Mean time between failures (MTBF) |
360000 h |
| Cutter |
Yes |
| Autocutter durability |
2.2 million cuts |
| Paper save function |
Yes |
| Tablet charge & sync |
Yes |
| Wall mountable |
Yes |
| Mounting position |
Horizontal/Vertical |
| Print head life |
150 km |
| Country of origin |
Philippines |
| Built-in sensors details |
Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor, Paper Jam Sensor, Receipt near-end sensor, Receipt paper sensor |
| Design |
|---|
| Product colour |
Black |
| Power |
|---|
| AC input voltage |
100 - 230 V |
| AC input frequency |
50 - 60 Hz |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
10 - 90% |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating temperature (T-T) |
5 - 45 °C |
| System requirements |
|---|
| Windows operating systems supported |
Yes |
| Mac compatibility |
Yes |
| Mobile operating systems supported |
Android, iOS |
| Weight & dimensions |
|---|
| Width |
127 mm |
| Depth |
127 mm |
| Height |
130 mm |
| Weight |
1.3 kg |
| Packaging data |
|---|
| Quantity per pack |
1 pc(s) |
| Package width |
210 mm |
| Package depth |
240 mm |
| Package height |
210 mm |
| Package weight |
2.31 kg |
| Logistics data |
|---|
| Products per pallet |
112 pc(s) |
| Products per pallet layer |
14 pc(s) |
| Products per pallet (UK) |
160 pc(s) |
| Products per pallet layer (UK) |
20 pc(s) |
| Technical details |
|---|
| Compliance certificates |
CE |
| Technology |
Thermal Line |
| Voltage |
24 V |
| Font styles |
ANK, Traditional Chinese, Simplified Chinese |
| Power consumption |
Mean:0.1 A, Mean Receipt unit: approx.1.8 A |
| Paper size roll paper |
79.50 ± 0.50 (W) mm x dia 83.00 mm,
57.50 ± 0.50 (W) mm x dia 83.00 mm |
| Print speed |
Max. 300 mm/sec at 203 x 203 DPI ( printing width80 mm) |
| Box contents |
AC adapter, AC cable, Main unit, Paper roll spacer, Quick Start Guide, Roll paper, Setup guide |
| Other features |
|---|
| Mean cycles between failures (MCBF) |
65000000 |
| Buffer size |
4 KB |
| Print head life (receipt unit) |
150 km |
