ELPDC21 - SXGA, VGA, USB-B, 2GB, HDMI, SD/SDHC, 13W, 2.6 kg, White
Bring lessons to life with this user-friendly document camera and share pictures and objects in Full HD on a large screen for the benefit of the whole class. Bursting with a range of clever features and functionality, teachers can create a dynamic environment to enhance student learning. Benefitting from a lightweight and portable design, it is easy to transport between classrooms.
Highlight the finest detail
This document camera is ideal when clear magnification is required, for example when studying historical texts. A 12x optical zoom plus 10x digital zoom and built-in LED light will ensure even intricate detail can be seen. Ideal for science lessons, minute objects can be displayed on a large screen thanks to a microscope attachment.
Display in Full HD
Display images and 3D objects in Full HD with incredible detail for the whole class to see. Thanks to a large A3 shooting area, two full pages from a textbook can be displayed. Smooth video streaming is achieved with impressive clarity and without motion blur at 30 frames per second.
Added flexibility
Live images and video content, including that stored on a SD card, can be output to multiple displays thanks to parallel video output. Thanks to split-screen functionality, teachers can present two pieces of content side-by-side to help highlight teaching points, such as plant and animal growth. Teachers can maintain student engagement by operating the document camera directly from the projected image at the front of the classroom, including starting and stopping video recordings.
Portable and lightweight
A lightweight and portable design and included soft carry case makes it easy to move between classrooms. With a Kensington lock and security bar, schools and education establishments can have added peace of mind when the camera is unattended or not in use.
| Camera |
|---|
| Optical sensor size |
25.4 / 2.7 mm (1 / 2.7") |
| Sensor type |
CMOS |
| Supported graphics resolutions |
1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1920 x 1080 (HD 1080) |
| Maximum video resolution |
1920 x 1080 pixels |
| Maximum frame rate |
30 fps |
| White balance |
Auto |
| Light exposure modes |
Auto |
| Image freeze |
Yes |
| Light source |
LED |
| Lens system |
|---|
| Auto focus |
Yes |
| Optical zoom |
12x |
| Digital zoom |
10x |
| Shooting area (WxD) |
297 x 420 mm |
| Ports & interfaces |
|---|
| Interface |
USB/HDMI |
| HDMI output ports quantity |
1 |
| USB connector type |
USB Type-B |
| Parallel connector |
Yes |
| DC-in jack |
Yes |
| VGA (D-Sub) output ports |
1 |
| VGA (D-Sub) input ports |
1 |
| Storage |
|---|
| Card reader integrated |
Yes |
| Compatible memory cards |
SD, SDHC |
| Maximum memory card size |
32 GB |
| Technical details |
|---|
| Document size (max) |
A3 |
| Product colour |
Grey, White |
| Display modes |
Microscope |
| Split screen |
Yes |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Focus |
Auto |
| Lamps quantity |
2 lamp(s) |
| Zoom capability |
Yes |
| Special features |
Auto focus, Freeze, Parallel video output, SD card viewer, Split screen, Zoom |
| Image viewer |
Yes |
| Compatible operating systems |
Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Mac OS X, Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista |
| Photo effects |
Black&White |
| Lamp type |
LED |
| Built-in microphone |
Yes |
| Country of origin |
Philippines |
| Image quality adjustment |
Brightness, Contrast |
| Bundled software |
Easy Interactive Tools, TWAIN-Treiber für Epson Dokumentenkamera (für Windows) |
| Image formats supported |
JPG |
| Box contents |
AC Adaptor, CD Manual, Carrying Case, VGA cable, Main unit, Microscope Adapter, Power cable, Quick Setup Guide, Remote control incl. batteries, Software (CD), USB cable |
| Output resolutions |
SXGA (1280*1024)/XGA (1024*768)/WXGA 16:10 (1280*800)/WXGA 16:9 (1360*768)/1080p (1920*1080), 480p/720p/1080p |
| Power |
|---|
| Power supply type |
DC |
| Power consumption (typical) |
13 W |
| Power consumption (standby) |
0.5 W |
| System requirements |
|---|
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista |
| Mac compatibility |
Yes |
| Mac operating systems supported |
Mac OS X 10.0 Cheetah, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Weight & dimensions |
|---|
| Width |
270 mm |
| Depth |
317 mm |
| Height |
447 mm |
| Weight |
2.6 kg |
| Packaging data |
|---|
| Quantity per pack |
1 pc(s) |
| Package width |
235 mm |
| Package depth |
445 mm |
| Package height |
173 mm |
| Package weight |
4.84 kg |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Software CD |
Yes |
| Manual |
Yes |
| Cables included |
AC |
| Carrying case |
Yes |
| Logistics data |
|---|
| Pallet height (UK) |
2.68 m |
| Pallet width (UK) |
100 cm |
| Pallet length (UK) |
120 cm |
| Pallet weight (UK) |
0 g |
| Products per pallet (UK) |
110 pc(s) |
| Products per pallet layer (UK) |
10 pc(s) |
| Products per pallet layer |
6 pc(s) |
| Pallet gross height |
2.68 m |
| Pallet gross width |
80 cm |
| Pallet gross length |
120 cm |
| Pallet gross weight |
0 g |
| Products per pallet |
66 pc(s) |
