DFX-9000Т, Matrix Printer, 1550cps, A4, Ethernet
The heavy duty dot matrix printer you can rely on
The Epson DFX-9000 is the fastest 9-pin heavy duty dot matrix printer in its class. Built to bring your business speed and reliability, it gives you the power to handle the most demanding workloads quickly and at exceptional value.
Built for demanding workloads, always ready for action
Working at high speeds
Take advantage of the fastest 9-pin heavy duty dot matrix printer in its class. With a 1,550cps print speed, the Epson DFX-9000 will deliver exceptional performance in all data processing and drafting tasks.
Working reliably
You can rely on the ongoing support of a print volume of 133 million lines MVBF*, an MTBF** of 20,000 power on hours and a 15 million characters ribbon life. Durability that keeps your business working.
Working in any environment
You can integrate the Epson DFX-9000 with existing equipment, using standard USB, Parallel and Serial interfaces (optional network, twinax, coax).
Working for your business
Utilise extensive paper handling solutions to deal with a wide range of commercial, industrial and logistic printing tasks.
Print up to 10 part forms on paper from 76.2 to 406.4mm wide. And extend your printing capabilities with the optional perforation cutter.
Key Features:
- Ethernet interface.
- Prints up to 10 part forms (1 original + 9 copies).
- Long ribbon life of 15 million characters.
- Standard USB, Serial and Parallel interfaces (optional network, twinax, coax).
- Flexible paper handling with two tractors as standard.
- Optional perforation cutter for automatic job separation, or for remote switching between paper sources.
| Printing |
|---|
| Built-in barcodes |
Code 39, POSTNET, UPC-A |
| Maximum number of copies |
10 copies |
| Normal print speed |
1320 cps |
| Maximum print speed (draft) |
1550 cps |
| Maximum printing width (columns) |
136 |
| Maximum resolution |
240 x 144 DPI |
| Colour |
No |
| Paper handling |
|---|
| Maximum print size |
A4 (210 x 297 mm) |
| Features |
|---|
| Country of origin |
Japan |
| Sound pressure level (printing) |
58 dB |
| Buffer size |
128 KB |
| Product colour |
Grey |
| Ports & interfaces |
|---|
| Optional connectivity |
USB 2.0 |
| Endurance |
|---|
| Mean time between failures (MTBF) |
20000 h |
| Ribbon life (black, draft) |
15 million characters |
| Print head life |
400000 million characters |
| Print head |
9-pin |
| Power |
|---|
| Power consumption (typical) |
185 W |
| Power consumption (standby) |
75 W |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
10 - 80% |
| Operating temperature (T-T) |
5 - 35 °C |
| System requirements |
|---|
| Windows operating systems supported |
Windows 2000, Windows 7, Windows 8, Windows 98, Windows XP |
| Bundled software |
Epson Status Monitor |
| Weight & dimensions |
|---|
| Weight |
34 kg |
| Height |
363 mm |
| Depth |
378 mm |
| Width |
700 mm |
| Packaging data |
|---|
| Package weight |
37.6 g |
| Package height |
505 mm |
| Package depth |
840 mm |
| Package width |
485 mm |
| Quantity per pack |
1 pc(s) |
| Technical details |
|---|
| Sustainability certificates |
ENERGY STAR |
| Other features |
|---|
| Connectivity technology |
Wired |
| Print technology |
Dot matrix |
| Power requirements |
100-240V, 50-60Hz |
| Dimensions (WxDxH) |
700 x 378 x 363 mm |
| Logistics data |
|---|
| Products per pallet |
4 pc(s) |
| Pallet gross length |
120 cm |
| Pallet gross width |
80 cm |
| Pallet gross height |
2.03 m |
| Products per pallet layer |
1 pc(s) |
| Products per pallet layer (UK) |
2 pc(s) |
| Products per pallet (UK) |
8 pc(s) |
| Pallet length (UK) |
120 cm |
| Pallet width (UK) |
100 cm |
| Pallet height (UK) |
2.03 m |
| Harmonized System (HS) code |
84433210 |
