EB-L520U
WUXGA laser display
Deliver professional content with sharp images and bright colours to any audience. The EB-L520U is designed to project a scalable laser display up to 500 inches, and offers a range of connectivity options to make content sharing an easy, seamless experience.
Featuring 5,200 lumens high-brightness capability, along with Full HD, WUXGA, 16:6 wide screen, support for 4K input and detail enhancement technology, it gives users brighter, more vivid displays of up to 500”.
Providing more premium features than you would typically expect to find in this display class, the EB-L520U delivers edge-blending and geometric correction to achieve one seamless large-format display. And for multimedia content, you can playback content without any lagging, and create playlists and set schedules directly from USB memory, all thanks to H.264 advanced video coding and the Epson Content Manager.
Flexibility is another hallmark of this display solution - a split-screen function allows two or four images from different sources to be combined in one large display; wired or optional wireless{s1 with support for Miracast{s1 makes connectivity simple and straightforward; and HDBaseT content can be shared and distributed without compromising on quality.
Thanks to the renowned market leading{s2 reliability of Epson laser displays, this fit and forget solution eliminates the need for regular maintenance. And for added confidence the EB-L520U comes with a standard 3-year warranty to provide lasting peace of mind.
| Projector |
|---|
| Projector brightness |
5200 ANSI lumens |
| Projection technology |
3LCD |
| Projector native resolution |
WUXGA (1920x1200) |
| Contrast ratio (typical) |
2500000:1 |
| Native aspect ratio |
16:10 |
| Screen size compatibility |
1270 - 12700 mm (50 - 500") |
| Contrast ratio (dynamic) |
5000000:1 |
| Number of colours |
1.07 billion colours |
| Projector brightness (economic mode) |
3640 ANSI lumens |
| Vertical scan range |
192 - 240 Hz |
| Matrix size |
1.7 cm (0.67") |
| Keystone correction, vertical |
±30° |
| Keystone correction, horizontal |
±30° |
| Light source |
|---|
| Light source type |
Laser |
| Service life of light source |
20000 h |
| Service life of light source (economic mode) |
30000 h |
| Lens system |
|---|
| Focus |
Manual |
| Focal length range |
20 - 31.8 mm |
| Aperture range (F-F) |
1.5 - 1.7 |
| Zoom capability |
Yes |
| Zoom type |
Manual |
| Zoom ratio |
1.6:1 |
| Throw ratio |
1.35 - 2.20:1 |
| Video |
|---|
| Analog signal format system |
Not supported |
| Full HD |
Yes |
| 3D |
No |
| Colour modes (2D) |
Cinema, Dynamic |
| Video processing |
10 bit |
| Video colour modes |
Cinema, DICOM simulation mode, Dynamic, Presentation, sRGB |
| Ports & interfaces |
|---|
| VGA (D-Sub) ports quantity |
3 |
| HDMI ports quantity |
2 |
| DVI port |
No |
| USB 2.0 ports quantity |
2 |
| USB 2.0 Type-B ports quantity |
1 |
| Audio (L/R) in |
1 |
| Serial interface type |
RS-232C |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, Wi-Fi 4 (802.11n) |
| Storage |
|---|
| Card reader integrated |
No |
| Features |
|---|
| Noise level |
31 dB |
| Noise level (economic mode) |
23 dB |
| Country of origin |
Philippines |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
1 |
| RMS rated power |
10 W |
| Design |
|---|
| Product type |
Standard throw projector |
| Market positioning |
Presentation |
| Product colour |
White |
| Placement |
Ceiling, Desktop, Floor, Wall |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| Power source |
AC |
| Power consumption (typical) |
293 W |
| Power consumption (standby) |
0.3 W |
| Power consumption (economy mode) |
223 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Software |
|---|
| Software support |
via: AMX, Crestron (Network), Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-10 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Weight |
7.7 kg |
| Width |
440 mm |
| Depth |
304 mm |
| Height |
122 mm |
| Package width |
495 mm |
| Package depth |
530 mm |
| Package height |
210 mm |
| Package weight |
10.4 kg |
| Packaging content |
|---|
| Remote control included |
Yes |
| Batteries included |
Yes |
| Warranty card |
Yes |
| Cables included |
AC, HDMI |
| Bundled software |
EasyMP Multi PC Projection |
| Technical details |
|---|
| Mobile app support |
Yes |
| Other features |
21:9 aspect ratio support, A/V mute, Arc Correction, Built-in speaker, CEC compatible, Easy OSD pre-setting, Edge Blending, Long light source life, PC Free, Quick Corner, Screen share, Source function, Ultra-wide display (16:6), iProjection App |
| Sustainability certificates |
TCO |
| Power consumption |
234 Watt (Normal On-Mode), 164 Watt (Eco On-Mode), 293 Watt (Normal Peak-mode), 223 Watt (Eco Peak-Mode), 0.3 Watt (Energy saving standby) |
| USB display function |
3 in 1: Image / Mouse / Sound |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
| Pallet weight (UK) |
0 g |
| Pallet gross weight |
0 g |
| Harmonized System (HS) code |
85286200 |
| Products per pallet (UK) |
14 pc(s) |
| Products per pallet |
14 pc(s) |
| Other features |
|---|
| Security features |
Kensington lock, Padlock, Security cable hole, Wireless LAN unit lock |
| Interface |
RS-232C, VGA in (2x), VGA out, HDMI in (2x), HDBaseT, Miracast (optional), Jack plug out, Jack plug in (2x), USB 2.0-A, USB 2.0, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac (optional) |
| Option type |
Air filter, Ceiling mount, Document camera, External Speaker, HDBaseT Transmitter, Safety wire set, Suspension adapter, WP System - ELPWP10, Wireless LAN unit, Wireless transmitter - ELPWT01 |
| Box contents |
HDMI Cable, Main unit, Power cable, Remote control incl. batteries, User guide, Warranty Documents |
| Control panel |
0.67 inch with C2 Fine |
