Super UST 4KE laser display
Super UST 4KE laser display
The EB-810E can be placed just centimetres away from a wall to create bright 4KE images up to 160”. It projects content in stunning clarity and offers a low cost, energy efficient large display solution with a convenient and quick set up.
EB-810E's super-ultra-short-throw lens allows discreet positioning close to the wall, enabling presenters free access without casting shadows.
With 5,000 lumens CLO and 3LCD technology, the EB-810E is bright and vibrant up-to 160", which enables content visibility from all angles and distances. The experience is immersive and it's extremely simple to use.
Versatile wired and wireless connectivity options, including Miracast™ screen mirroring, ensure effortless, multi-device content sharing.
Weighing only 12.3kg, it is highly portable, and the Epson Setting Assistant App makes setup quick and simple. The ideal display solution suitable for different room sizes, combined with flexible installation options.
The EB-810E supports multiple aspect ratios and multi-projector edge-blending for a low cost, seamless, energy efficient ultra-wide display, perfect for video conferencing.
Paired with Epson's Ambient Light Rejection Screen, the EB-810E's image quality could be mistaken for a video wall or LED display, but it is surprisingly affordable and consumes a fraction of the energy.
| Projector |
|---|
| Projector brightness |
5000 ANSI lumens |
| Projection technology |
3LCD |
| Projector native resolution |
1080p (1920x1080) |
| Contrast ratio (typical) |
2500000:1 |
| Native aspect ratio |
16:9 |
| Smart projector |
No |
| Screen size compatibility |
2032 - 4064 mm (80 - 160") |
| Contrast ratio (dynamic) |
5000000:1 |
| Projector brightness (economic mode) |
3500 ANSI lumens |
| Vertical scan range |
192 - 240 Hz |
| Heat dissipation |
1292 BTU/h |
| Light source |
|---|
| Light source type |
Laser |
| Service life of light source |
20000 h |
| Service life of light source (economic mode) |
30000 h |
| Lens system |
|---|
| Focus |
Manual |
| Focal length range |
2.3 mm |
| Fixed focal length |
2.3 mm |
| F-number (relative aperture) |
1.8 |
| Zoom capability |
Yes |
| Zoom ratio |
1.35:1 |
| Throw ratio |
0.16 - 0.22:1 |
| Video |
|---|
| Analog signal format system |
Not supported |
| Full HD |
Yes |
| 3D |
No |
| Colour modes (2D) |
Cinema, Dynamic, Natural |
| Video processing |
10 bit |
| Video colour modes |
Blackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation |
| Ports & interfaces |
|---|
| HDMI ports quantity |
3 |
| DVI port |
No |
| HDBaseT port |
Yes |
| Service port type |
USB Type-B |
| USB 2.0 ports quantity |
2 |
| USB 2.0 Type-A ports quantity |
2 |
| Serial interface type |
RS-232C |
| Network |
|---|
| Smart TV |
No |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Miracast |
Yes |
| Storage |
|---|
| Card reader integrated |
No |
| Features |
|---|
| Interactive |
No |
| Noise level |
35 dB |
| Noise level (economic mode) |
26 dB |
| High Dynamic Range (HDR) technology |
High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG) |
| High Dynamic Range (HDR) supported |
Yes |
| Password protection |
Yes |
| Multimedia |
|---|
| Built-in speaker(s) |
No |
| Design |
|---|
| Product type |
Ultra short throw projector |
| Market positioning |
Business |
| Product colour |
White |
| Placement |
Ceiling, Desktop, TV cabinet, Wall |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| Power source |
AC |
| Power consumption (typical) |
290 W |
| Power consumption (max) |
380 W |
| Power consumption (PowerSave) |
0.4 W |
| Power consumption (economy mode) |
286 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-10 - 60 °C |
| Storage temperature (T-T) |
-10 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Weight |
12.5 kg |
| Width |
695 mm |
| Depth |
341 mm |
| Height |
156 mm |
| Package width |
460 mm |
| Package depth |
790 mm |
| Package height |
325 mm |
| Package weight |
16.9 kg |
| Packaging content |
|---|
| Remote control included |
Yes |
| Batteries included |
Yes |
| Cables included |
AC |
| Bundled software |
Epson Creative Projection, EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management, Epson Setting Assistant |
| Technical details |
|---|
| Mobile app support |
Yes |
| Other features |
21:9 aspect ratio support, 4K enhancement, A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Daisy chain Multi-Projection, Digital zoom, Direct Power on/off, Document Camera Compatible, Edge Blending, Email notification, Fit to Screen, Home Screen, Horizontal and vertical keystone correction, Image Shift, JPEG Viewer, Long light source life, PC Free, Point correction, Power on button, Quick Corner, Schedule Function, Screen Mirroring, Source function, Split-Screen-Function, Ultra-wide display (16:6), Web Control, Web Remote, Wireless LAN capable, iProjection App |
| Power consumption |
290 Watt (Normal On-Mode), 192 Watt (Eco On-Mode), 380 Watt (Normal Peak-mode), 286 Watt (Eco Peak-Mode), 0.4 Watt (Energy saving standby) |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
| Pallet height (UK) |
2.1 m |
| Pallet length (UK) |
120 cm |
| Products per pallet layer (UK) |
2 pc(s) |
| Products per pallet layer |
2 pc(s) |
| Pallet gross height |
2.1 m |
| Pallet gross width |
80 cm |
| Pallet gross length |
120 cm |
| Products per pallet (UK) |
12 pc(s) |
| Products per pallet |
12 pc(s) |
| Other features |
|---|
| Security features |
Kensington lock, Control panel lock, Password lock, Padlock, Wireless LAN unit lock, Wireless LAN security, Password protection |
| Interface |
USB 2.0-A (2x), USB 2.0 Type B (Service Only), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, HDMI in (2x), HDMI out, HDBaseT, Miracast |
| Supported network protocols |
HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink |
| Option type |
Air filter, Ceiling mount, Connection and control box, MB22 ceiling mount, Safety wire set, Visualiser camera, WP System - ELPWP10, WP System - ELPWP20, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01 |
| Box contents |
Power cable, Quick Start Guide, Remote control incl. batteries, Warranty Documents |
| Control panel |
0.62 inch with C2 Fine |
