4600 - 3200 Lumen, 1080p, 16:9, 2500000:1, 10 Bits, 192 Hz - 240 Hz, 260W, AC 220-240 V, 50-60 Hz
Wireless laser projector
Combined with advance features, the EB-L260F is an entry-level Full HD wireless laser projector the ideal solution for any working environment. It offers 4,600 lumens brightness, a range of wireless and wired connectivity and the ability to have a scalable display size of up to 310 inches.
| Projector |
|---|
| Projector brightness |
4600 ANSI lumens |
| Projection technology |
3LCD |
| Projector native resolution |
1080p (1920x1080) |
| Contrast ratio (typical) |
2500000:1 |
| Native aspect ratio |
16:9 |
| Screen size compatibility |
787.4 - 7874 mm (31 - 310") |
| Projection distance (wide) |
0.9 - 9.1 m |
| Contrast ratio (dynamic) |
5000000:1 |
| Number of colours |
1.07 billion colours |
| Projector brightness (economic mode) |
3200 ANSI lumens |
| Vertical scan range |
192 - 240 Hz |
| Keystone correction, vertical |
±30° |
| Keystone correction, horizontal |
±30° |
| Heat dissipation |
884 BTU/h |
| Light source |
|---|
| Light source type |
Laser |
| Service life of light source |
20000 h |
| Service life of light source (economic mode) |
30000 h |
| Lens system |
|---|
| Focus |
Manual |
| Focal length range |
18.2 - 29.1 mm |
| Aperture range (F-F) |
1.51 - 1.77 |
| Zoom capability |
Yes |
| Zoom type |
Manual |
| Zoom ratio |
1:1.62 |
| Throw ratio |
1.32 - 2.12:1 |
| Offset |
1000% |
| Video |
|---|
| Full HD |
Yes |
| Colour modes (2D) |
Cinema, Dynamic |
| Video processing |
10 bit |
| Video colour modes |
Blackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Presentation, sRGB |
| Ports & interfaces |
|---|
| VGA (D-Sub) ports quantity |
3 |
| HDMI ports quantity |
2 |
| Composite video in |
1 |
| USB 2.0 ports quantity |
2 |
| USB 2.0 Type-A ports quantity |
1 |
| Audio (L/R) in |
2 |
| Audio (L/R) out |
1 |
| Microphone in |
Yes |
| Serial interface type |
RS-232C |
| AC (power) in |
Yes |
| Audio Return Channel (ARC) |
Yes |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Wi-Fi |
Yes |
| Wi-Fi standards |
Wi-Fi 5 (802.11ac) |
| Miracast |
Yes |
| Features |
|---|
| Noise level |
37 dB |
| Noise level (economic mode) |
27 dB |
| HDCP |
Yes |
| Projection modes |
Ceiling, Front |
| On Screen Display (OSD) |
Yes |
| Screen mirroring |
Yes |
| Air filter |
Yes |
| Country of origin |
Philippines |
| Password protection |
Yes |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
16 W |
| Design |
|---|
| Product type |
Standard throw projector |
| Product colour |
White |
| Placement |
Ceiling, Desktop, Floor, Wall |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Power |
|---|
| Power source |
AC |
| Power consumption (typical) |
199 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (max) |
260 W |
| Power consumption (economy mode) |
144 W |
| AC input voltage |
220 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-10 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Weight |
4.15 kg |
| Width |
325 mm |
| Depth |
299 mm |
| Height |
90 mm |
| Package width |
380 mm |
| Package depth |
495 mm |
| Package height |
190 mm |
| Package weight |
5.93 kg |
| Packaging content |
|---|
| Remote control included |
Yes |
| Batteries included |
Yes |
| Cables included |
HDMI, Power |
| Bundled software |
Epson Creative Projection, EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management |
| Technical details |
|---|
| Mobile app support |
Yes |
| Other features |
AV Mute Slide, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Direct Power on/off, Document Camera Compatible, Edge Blending, Home Screen, Horizontal and vertical keystone correction, Long light source life, OSD copy function, PC Free, Quick Corner, Schedule Function, Screen Mirroring, Screen share, Split-Screen-Function, Super resolution, Web Control, Wireless LAN capable, iProjection App |
| Power consumption |
201 Watt (Normal On-Mode), 260 Watt (Normal Peak-mode), 191 Watt (Eco Peak-Mode), 0.5 Watt (Energy saving standby) |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
| Pallet height (UK) |
2.24 m |
| Pallet length (UK) |
120 cm |
| Products per pallet layer (UK) |
6 pc(s) |
| Products per pallet layer |
4 pc(s) |
| Pallet gross height |
2.24 m |
| Pallet gross width |
80 cm |
| Pallet gross length |
120 cm |
| Products per pallet (UK) |
66 pc(s) |
| Products per pallet |
44 pc(s) |
| Other features |
|---|
| Security features |
Kensington lock, Security bar, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection |
| Interface |
USB 2.0-A, USB 2.0, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wi-Fi Direct, VGA in (2x), VGA out, Composite in, Miracast, Jack plug out, Jack plug in (2x), Cinch audio out, Microphone input, HDMI (HDCP 2.2) (2x), Wireless LAN IEEE 802.11a/b/g/n/ac |
| Supported network protocols |
HTTPS, IPv6, SNMP, ESC/VP.net, PJLink |
| Option type |
Air filter, Ceiling mount, Connection and control box, Document camera, External Speaker, Safety wire set, Suspension adapter, WP System - ELPWP10, Wall mount, Wireless transmitter - ELPWT01 |
| Box contents |
HDMI Cable, Main unit, Power cable, Quick Start Guide, Remote control incl. batteries, Warranty card |
| Control panel |
0.62 inch with C2 Fine |
