4600 lm, Full HD, Laser, 10 Bits, 31" - 310", LAN, WLAN, USB 2.0-A, Loudspeaker 16 W, 4.2 kg
Digital signage projector
The EB-L265F is a cost-effective laser display solution with easy and flexible installation. It can be installed on floor, wall or ceiling (including on a lighting track). A single projector can create a display of up to 310" with a range of flexible content source options including local content playback support (via a memory card), Miracast wireless connectivity and HDMI.
Innovative and cost effective
Epson's advanced laser technology is bright, robust and reliable for a flexible and easy to use digital signage solution. It offers bright and vivid colours in a cost-effective solution capable of creating large displays or even projecting onto 3D objects.
Flexible display options
The EB-L265F enables scalable display sizes of up to 310 inches with a single projector - even larger when edge-blending 2 units. Full HD, 4,600 lumen brightness and 3LCD technology offer bright colours and high quality - perfect for creating engaging and informative displays, even in bright spaces.
It can be mounted wherever needed - wall, floor or ceiling (inc.on a lighting track) with optional accessories. A white model is also available (EB-L260F) to ensure the projector is as discrete as possible.
Create dynamic content
Epson offers free apps for content creation (Epson Creative Projection & Epson Projector Content Management). Content can be played directly from USB (including playlists, videos, and signage content) using the built-in playback feature. Users can even upload and playback content wirelessly with built-in Wi-Fi and Miracast functionality.
Low maintenance and high reliability
Up to 20,000 hours maintenance-free use using a laser light source with a 5 year warranty make this a cost-effective fit-and-forget display solution you can rely on.
| Projector |
|---|
| Projector brightness |
4600 ANSI lumens |
| Projection technology |
3LCD |
| Projector native resolution |
1080p (1920x1080) |
| Contrast ratio (typical) |
2500000:1 |
| Native aspect ratio |
16:9 |
| Smart projector |
No |
| Screen size compatibility |
787.4 - 7874 mm (31 - 310") |
| Contrast ratio (dynamic) |
5000000:1 |
| Number of colours |
1.07 billion colours |
| Projector brightness (economic mode) |
3200 ANSI lumens |
| Vertical scan range |
192 - 240 Hz |
| Matrix size |
1.57 cm (0.62") |
| Keystone correction, vertical |
±30° |
| Keystone correction, horizontal |
±30° |
| Heat dissipation |
884 BTU/h |
| Light source |
|---|
| Light source type |
Laser |
| Service life of light source |
20000 h |
| Service life of light source (economic mode) |
30000 h |
| Lens system |
|---|
| Focus |
Manual |
| Focal length range |
18.2 - 29.1 mm |
| Aperture range (F-F) |
1.51 - 1.77 |
| Zoom capability |
Yes |
| Zoom type |
Manual |
| Zoom ratio |
1:1.62 |
| Throw ratio |
1.32 - 2.12:1 |
| Video |
|---|
| Analog signal format system |
Not supported |
| Full HD |
Yes |
| 3D |
Yes |
| Video processing |
10 bit |
| Video colour modes |
Blackboard, Cinema, Dynamic, Multi-projection, Presentation, sRGB |
| Ports & interfaces |
|---|
| VGA (D-Sub) ports quantity |
3 |
| HDMI ports quantity |
2 |
| Composite video in |
1 |
| DVI port |
No |
| Service port type |
USB Type-B |
| USB 2.0 ports quantity |
1 |
| Headphone outputs |
3 |
| Serial interface type |
RS-232C |
| Network |
|---|
| Smart TV |
No |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Storage |
|---|
| Card reader integrated |
No |
| Features |
|---|
| Interactive |
No |
| Noise level |
37 dB |
| Noise level (economic mode) |
27 dB |
| HDCP |
Yes |
| Country of origin |
Philippines |
| Password protection |
Yes |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
16 W |
| Design |
|---|
| Market positioning |
Presentation |
| Product colour |
Black |
| Placement |
Ceiling, Desktop, Floor, Lighting track, Wall |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| Power source |
AC |
| Power consumption (typical) |
199 W |
| Power consumption (economy mode) |
144 W |
| AC input voltage |
220 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-10 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Weight |
4.2 kg |
| Package width |
405 mm |
| Package depth |
490 mm |
| Package height |
190 mm |
| Package weight |
6.29 kg |
| Packaging content |
|---|
| Remote control included |
Yes |
| Batteries included |
Yes |
| Cables included |
AC, HDMI |
| Bundled software |
Epson Creative Projection, EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management |
| Technical details |
|---|
| Mobile app support |
Yes |
| Other features |
A/V mute, Arc Correction, Auto Power On, Auto source search, Automatic keystone correction, Built-in speaker, CEC compatible, Customizable user logo, Direct Power on/off, Document Camera Compatible, Edge Blending, Home Screen, Horizontal and vertical keystone correction, Long light source life, OSD copy function, PC Free, Quick Corner, Schedule Function, Screen Mirroring, Split-Screen-Function, Super resolution, Web Control, Web Remote, Wireless LAN capable, iProjection App |
| Power consumption |
199 Watt (Normal On-Mode), 144 Watt (Eco On-Mode), 260 Watt (Normal Peak-mode), 191 Watt (Eco Peak-Mode), 0.5 Watt (Energy saving standby) |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
| Pallet height (UK) |
2.24 m |
| Pallet length (UK) |
120 cm |
| Products per pallet layer (UK) |
4 pc(s) |
| Products per pallet layer |
2 pc(s) |
| Pallet gross height |
2.24 m |
| Pallet gross width |
80 cm |
| Pallet gross length |
120 cm |
| Products per pallet (UK) |
44 pc(s) |
| Products per pallet |
22 pc(s) |
| Other features |
|---|
| Security features |
Kensington lock, Security bar, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection |
| Interface |
USB 2.0-A, USB 2.0 Type B (Service Only), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, VGA in (2x), VGA out, Composite in, Miracast, Jack plug out, Jack plug in (2x), HDMI (HDCP 2.3) (2x) |
| Supported network protocols |
HTTPS, IPv6, SNMP, ESC/VP.net, PJLink |
| Option type |
Air filter, Ceiling mount, Connection and control box, Document camera, External Speaker, Safety wire set, WP System - ELPWP10, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01 |
| Box contents |
Cable cover, HDMI Cable, Main unit, Power cable, Remote control incl. batteries, User guide, Warranty document |
| Control panel |
0.62 inch with C2 Fine |
