3LCD, 4.000 Lumen, WXGA 2, 2.500.000 : 1, 100 Hz - 120 Hz, 260 W, AC 100 V - 240 V, 50 Hz - 60 Hz, 325 x 337 x 90 mm, 4600 g
Agile ST laser display
The EB-L210SW delivers quality images and a host of features as standard to give users more for value, producing a bright and vibrant HD image up to 120". Its compact and light weight design makes this a perfect mobile display solution for meetings, or it can be wall or ceiling mounted for a permanent solution, freeing up workspace.
The EB-L210SW's short throw lens allows close positioning of the projector to the display, ideal for small rooms and reducing the risk of shadows cast onto the display.
Unlike some other brand projectors, EB-L210SW features 3LCD technology, enabling 4,000 lumens Colour and White Light Output levels for a bright and vibrant display. The experience is immersive and user-friendly.
Scalable from 53-120", display sizes can be optimised for each room with one product and at a fixed cost, and produce a large display up-to 125", clearly visible from all angles and at a distance.
The EB-L210SW can be portable, and there is no glass flat panel to create disruptive, reflected blind spots at certain angles.
Versatile wired and wireless connectivity options, including Miracast™ screen mirroring, ensures effortless, multi-device content sharing, and with a connected optional Epson visualiser, documents, presentations or 3D objects can be projected in incredible detail to the whole room. With USB 2A power output, HDMI streaming sticks can also be connected to open further possibilities.
| Projector |
|---|
| Projector brightness |
4000 ANSI lumens |
| Projection technology |
3LCD |
| Projector native resolution |
WXGA (1280x800) |
| Contrast ratio (typical) |
2500000:1 |
| Native aspect ratio |
16:10 |
| Supported aspect ratios |
16:10 |
| Screen size compatibility |
1346.2 - 7620 mm (53 - 300") |
| Contrast ratio (dynamic) |
5000000:1 |
| Number of colours |
1.07 billion colours |
| Projector brightness (economic mode) |
2800 ANSI lumens |
| Vertical scan range |
100 - 120 Hz |
| Keystone correction, vertical |
±15° |
| Keystone correction, horizontal |
±15° |
| Heat dissipation |
884 BTU/h |
| Light source |
|---|
| Light source type |
Laser |
| Service life of light source |
20000 h |
| Service life of light source (economic mode) |
30000 h |
| Lens system |
|---|
| Focus |
Auto/Manual |
| Focal length range |
9.5 mm |
| Fixed focal length |
9.5 mm |
| Zoom capability |
Yes |
| Zoom ratio |
1.35:1 |
| Throw ratio |
0.48 - 0.65:1 |
| Video |
|---|
| 3D |
Yes |
| Colour modes (2D) |
Cinema, Dynamic |
| Video processing |
10 bit |
| Video colour modes |
Blackboard, Cinema, Dynamic, Presentation, sRGB |
| Ports & interfaces |
|---|
| VGA (D-Sub) ports quantity |
2 |
| HDMI ports quantity |
2 |
| DVI port |
No |
| USB 2.0 ports quantity |
1 |
| USB 2.0 Type-B ports quantity |
1 |
| Audio (L/R) in |
2 |
| Audio (L/R) out |
1 |
| Microphone in |
Yes |
| Serial interface type |
RS-232C |
| AC (power) in |
Yes |
| Consumer Electronics Control (CEC) support |
Yes |
| Audio Return Channel (ARC) |
Yes |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Miracast |
Yes |
| Web browser |
Yes |
| Features |
|---|
| Interactive |
No |
| Noise level |
37 dB |
| Noise level (economic mode) |
27 dB |
| On Screen Display (OSD) |
Yes |
| Screen mirroring |
Yes |
| Country of origin |
Philippines |
| Password protection |
Yes |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
16 W |
| Design |
|---|
| Product type |
Short throw projector |
| Market positioning |
Portable |
| Product colour |
White |
| Placement |
Ceiling, Desktop, Wall |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| Power source |
AC |
| Power consumption (typical) |
201 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (max) |
260 W |
| Power consumption (economy mode) |
191 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Auto power off |
Yes |
| Supplier features |
|---|
| Recommended gender |
Any gender |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-10 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Weight |
4.6 kg |
| Width |
325 mm |
| Depth |
337 mm |
| Height |
90 mm |
| Package width |
420 mm |
| Package depth |
535 mm |
| Package height |
235 mm |
| Package weight |
7.11 kg |
| Packaging content |
|---|
| Remote control included |
Yes |
| Cables included |
AC, HDMI |
| Bundled software |
EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management |
| Technical details |
|---|
| Mobile app support |
Yes |
| Other features |
Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Digital zoom, Direct Power on/off, Document Camera Compatible, Easy OSD pre-setting, Email notification, Home Screen, Horizontal and vertical keystone correction, Instant on/off, Long light source life, Mail notification function, Microphone input, Network administration, Network projection, OSD copy function, Quick Corner, Screen Mirroring, Set-up wizard, Split-Screen-Function, Web Control, Web Remote, Wireless LAN capable, iProjection App |
| Power consumption |
201 Watt (Normal On-Mode), 144 Watt (Eco On-Mode), 260 Watt (Normal Peak-mode), 191 Watt (Eco Peak-Mode), 0.5 Watt (Energy saving standby) |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
| Pallet height (UK) |
2.03 m |
| Pallet length (UK) |
120 cm |
| Products per pallet layer (UK) |
4 pc(s) |
| Products per pallet layer |
2 pc(s) |
| Pallet gross height |
2.03 m |
| Pallet gross width |
80 cm |
| Pallet gross length |
120 cm |
| Products per pallet (UK) |
32 pc(s) |
| Products per pallet |
16 pc(s) |
| Other features |
|---|
| Security features |
Kensington lock, Control panel lock, Password lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection |
| Interface |
USB 2.0, USB 2.0 Type B (Service Only), RS-232C, Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, Wi-Fi Direct, VGA in (2x), VGA out, HDMI in (2x), Miracast, Jack plug out, Jack plug in (2x), Microphone input |
| Mounting |
Ceiling Mounted, Table Mounted, Wall Mounted |
| RS-232C |
Yes |
| Supported network protocols |
HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink |
| Option type |
Ceiling mount, Connection and control box, External Speaker, Visualiser camera, Wall mount |
| Box contents |
HDMI Cable 1.8m, Power cable, Quick Start Guide, Remote control incl. batteries, Warranty Documents |
| Control panel |
0.59 inch with C2 Fine |
