Dell Pro Max Tower T2 FCT2250|U7 265|16GB|512GB SSD|Intel Graphics|W11 Pro|Kb|vPro ProSupport Next Business Day Onsite Service after remote diagnosis with HW-SW Support, 36 Month(s)
| Processor |
|---|
| Processor manufacturer |
Intel |
| Processor family |
Intel Core Ultra 7 |
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor model |
265 |
| Processor cores |
20 |
| Processor threads |
20 |
| Processor boost frequency |
5.3 GHz |
| Performance cores |
8 |
| Efficient cores |
12 |
| Performance-core Max Turbo Frequency |
5.2 GHz |
| Efficient-core Max Turbo Frequency |
4.6 GHz |
| Performance-core base frequency |
2.4 GHz |
| Efficient-core base frequency |
1.8 GHz |
| Processor cache |
30 MB |
| Processor cache type |
Smart Cache |
| Number of processors installed |
1 |
| Maximum turbo power |
182 W |
| Processor base power |
65 W |
| Neural processor unit (NPU) |
|---|
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to |
33 TOPs |
| NPU performance up to |
13 TOPs |
| GPU performance up to |
8 TOPs |
| Memory |
|---|
| Internal memory |
16 GB |
| Maximum internal memory |
128 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory layout (slots x size) |
1 x 16 GB |
| Memory slots |
4x DIMM |
| Memory data transfer rate |
5600 MT/s |
| Memory channels |
Single-channel |
| Non-ECC |
Yes |
| Storage |
|---|
| Total storage capacity |
512 GB |
| Optical drive type |
No |
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| Total SSDs capacity |
512 GB |
| Number of SSDs installed |
1 |
| SSD memory type |
TLC |
| SSD capacity |
512 GB |
| NVMe |
Yes |
| SSD interface |
PCI Express |
| SSD form factor |
M.2 |
| M.2 SSD size |
2280 (22 x 80 mm) |
| Graphics |
|---|
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel® Graphics |
| On-board graphics card model |
Intel® Graphics |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| LAN controller |
Intel® I219-LM |
| Wi-Fi |
No |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| USB 3.2 Gen 2x2 Type-C ports quantity |
2 |
| Intel® Thunderbolt 4 |
Yes |
| Thunderbolt 4 ports quantity |
1 |
| DisplayPorts quantity |
2 |
| DisplayPort version |
1.4a |
| Ethernet LAN (RJ-45) ports |
1 |
| Combo headphone/mic port |
Yes |
| DC-in jack |
Yes |
| Number of front USB ports |
4 |
| Number of rear USB ports |
6 |
| Number of SATA III connectors |
4 |
| Expansion slots |
|---|
| PCI Express x4 (Gen 3.x) slots |
2 |
| PCI Express x4 (Gen 4.x) slots |
1 |
| PCI Express x16 (Gen 5.x) slots |
1 |
| Design |
|---|
| Chassis type |
Tower |
| Volume |
32 L |
| Placement supported |
Vertical |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Product colour |
Black |
| Intel® vPro™ Platform Eligibility |
Yes |
| Performance |
|---|
| Product type |
PC |
| Market positioning |
Business |
| Motherboard chipset |
Intel W880 |
| Audio chip |
Realtek ALC3204 |
| Audio system |
High Definition Audio |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Software |
|---|
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Trial software |
McAfee Business Protection 1-year,Activate Your Microsoft 365 For A 30 Day Trial |
| Power |
|---|
| Power supply |
1500 W |
| Power supply input voltage |
90 - 264 V |
| Power supply input frequency |
47/63 Hz |
| 80 PLUS certification |
80 PLUS Platinum |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 35 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
-15.2 - 3048 m |
| Non-operating altitude |
-15.2 - 10668 m |
| Operating vibration |
0.66 G |
| Non-operating vibration |
1.3 G |
| Operating shock |
110 G |
| Non-operating shock |
160 G |
| Sustainability |
|---|
| Doesn't contain |
PVC/BFR |
| Sustainability certificates |
ENERGY STAR, EPEAT Climate + |
| Weight & dimensions |
|---|
| Width |
187.7 mm |
| Depth |
438 mm |
| Height |
387 mm |
| Weight |
9.7 kg |
| Packaging content |
|---|
| Display included |
No |
| Cables included |
AC |
| General |
|---|
| Product family |
Pro Max |
| Carbon footprint |
|---|
| PAIA version |
GaBi version 1, 2024 |
| Carbon emissions (End-of-Life) |
13.8 |
| Carbon emissions (Use) |
231.42 |
| Carbon emissions (Logistics) |
15.43 |
| Carbon emissions (Manufacturing) |
145.35 |
| Total carbon footprint |
406 |
