600W, APFC, ATX 24 pin, 2x PCI-e 6+2 Pin, EPS, 5x SATA, 3x Molex, 120 mm, 200 - 240V, 50/60Hz, 140 x 150 x 86 mm, 1.49 kg
NEX Level Power
The ELITE NEX White is the dependable choice for entry level builders looking for a strong, reliable PSU.
Active power factor correction and a dual forward topology design
Constructed with protective measures normally only found in high-end power supplies that improve overall safety and current stability.
Excellent temperature resistance
Capable of comfortably operating at 40°C under full loads, allowing for a longer lifespan even in warmer environments.
High peak power tolerance
Can reliably push an additional 100W at peak power loads for up to 20 seconds.
Durability, reliability, and safety
Will perform consistently in any environment, whether you live at high altitudes or in high humidity.
80 Plus standard certified efficiency
Maintains an efficiency of 85% at typical loads.
PSU CALCULATOR
Need help choosing the right power supply for your system?
Try out our comprehensive and easy-to-use PSU calculator.
| Power |
|---|
| Total power |
600 W |
| AC input voltage |
200 - 240 V |
| AC input frequency |
50/60 Hz |
| Input current |
4.5 A |
| Power Factor Correction (PFC) type |
Active |
| Combined power (+3.3V) |
110 W |
| Combined power (+12V) |
552 W |
| Combined power (+5V) |
110 W |
| Combined power (-12V) |
3.6 W |
| Combined power (+5Vsb) |
12.5 W |
| Max output current (+3.3V) |
19 A |
| Max output current (+12V) |
46 A |
| Max output current (+5V) |
17 A |
| Max output current (-12V) |
0.3 A |
| Max output current (+5Vsb) |
2.5 A |
| Power Good signal delay range |
100 - 500 ms |
| Hold time |
10 ms |
| Efficiency |
85% |
| Power protection features |
Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Ports & interfaces |
|---|
| Motherboard power connector |
24-pin ATX |
| Motherboard power cable length |
50 cm |
| Number of SATA power connectors |
5 |
| SATA power cable length |
150,400 mm |
| Peripheral (Molex) power connectors (4-pin) |
3 |
| Peripheral (Molex) power cable length |
150,400 mm |
| EPS power connector (4+4 pin) |
Yes |
| PCI Express power connectors (6+2 pin) |
2 |
| ATX Power connector (24-pin) |
Yes |
| Cabling type |
Non-Modular |
| Performance |
|---|
| Purpose |
PC |
| Power supply unit (PSU) form factor |
ATX |
| 80 PLUS certification |
80 PLUS |
| Supported motherboard form factors |
ATX |
| ATX version |
2.41 |
| Mean time between failures (MTBF) |
100000 h |
| Certification |
TUV,cTUVus,CE,FCC,CCC,EAC,UKCA |
| Design |
|---|
| Product colour |
Black |
| Cooling type |
Active |
| Fan diameter |
12 cm |
| Number of fans |
1 fan(s) |
| Fan location |
Top |
| On/off switch |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Width |
150 mm |
| Depth |
140 mm |
| Height |
86 mm |
| Weight |
1.49 kg |
| Packaging data |
|---|
| Package width |
190 mm |
| Package depth |
280 mm |
| Package height |
95 mm |
| Package weight |
1.88 kg |
| Package type |
Box |
| Other features |
|---|
| Legal guarantee |
3 year(s) |
