XF-405, 4K UHD, 1.0" CMOS, 8.29 (13.4) MPix, 15x Zoom, 8.3-124.5mm, Dual Pixel CMOS AF, 0.24" TFT, 3.5" LCD, 2 x SD/SDHC/SDXC, Mini-HDMI, RJ-45, USB Mini-B
The XF405 Professional Camcorder offers an outstanding combination of 4K UHD image quality, features and unctionality in a compact portable design ideally suited for on-the-go Electronic News Gathering (ENG) and documentary production.
Featuring a 1.0-inch 4K UHD CMOS image sensor and dual DIGIC DV 6 Image Processors, the XF405 records in MP4 format to dual SD card slots. The camcorder is capable of recording 4K UHD video at 60p, as well as slow motion ecording up to 120fps in Full HD. A 15x optical zoom lens maintains 4K UHD quality throughout the entire zoom range, while the camcorder's Dual Pixel CMOS AF helps facilitate fast and accurate autofocus.
The camcorder includes an HDMI 2.0 terminal with 4K UHD output support, two XLR terminals with independent audio level control and a 3G-SDI output that supports camcorder integration into professional workflows. An adjustable 3.5-inch touch panel LCD monitor and a built-in 0.24-inch electronic viewfinder enhance usability, and the detachable handle helps the XF405 to operate in a variety of shooting situations. Designed to meet the needs of professionals, the XF405 offers a wide range of recording possibilities.
| Image sensor |
|---|
| Total megapixels |
8.29 MP |
| Sensor type |
CMOS |
| Effective megapixels (movie) |
13.4 MP |
| Lens system |
|---|
| Optical zoom |
15x |
| Image stabilizer |
Yes |
| Focal length range |
8.3 - 124.5 mm |
| Focal length (35mm film equivalent) |
25.5 - 382.5 mm |
| Minimum aperture number |
2.8 |
| Maximum aperture number |
4.5 |
| Storage |
|---|
| Camcorder media type |
Memory card |
| Compatible memory cards |
SD, SDHC, SDXC |
| Disc types supported |
No |
| Camcorder tape type |
No |
| Focusing |
|---|
| Focus adjustment |
Auto |
| Exposure |
|---|
| Light exposure modes |
Manual |
| White balance |
|---|
| White balance |
Auto, Daylight, Tungsten |
| Flash |
|---|
| Built-in light |
No |
| Built-in flash |
No |
| Shutter |
|---|
| Camera shutter speed |
1/30 - 1/2 s |
| Display |
|---|
| Display diagonal |
8.89 cm (3.5") |
| Built-in display |
Yes |
| Display |
TFT LCD |
| Flip-out screen |
No |
| Display resolution (numeric) |
1560000 pixels |
| Viewfinder |
|---|
| Viewfinder type |
Electronic |
| Viewfinder resolution (approx.) |
1560000 pixels |
| Viewfinder screen size |
0.24" |
| Camera |
|---|
| Camcorder type |
Handheld camcorder |
| Design |
|---|
| Product colour |
Black |
| LED indicators |
Yes |
| Video |
|---|
| HD type |
4K Ultra HD |
| Maximum video resolution |
3840 x 2160 pixels |
| Video resolutions |
1280 x 720,1920 x 1080,3840 x 2160 |
| Video formats supported |
H.264, M-JPEG, MP4 |
| Supported video modes |
720p, 1080p, 2160p |
| Ports & interfaces |
|---|
| HDMI |
Yes |
| Mini HDMI ports quantity |
1 |
| USB connectivity |
Yes |
| Mini-USB 2.0 ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Headphone connectivity |
3.5 mm |
| Headphone outputs |
1 |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet interface type |
Fast Ethernet, Gigabit Ethernet |
| General |
|---|
| Product family |
XF |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage relative humidity (H-H) |
0 - 60% |
| Operating relative humidity (H-H) |
0 - 85% |
| Storage temperature (T-T) |
-5 - 45 °C |
| Weight & dimensions |
|---|
| Depth |
214 mm |
| Height |
97 mm |
| Weight |
1.67 kg |
