36", 2400×1200dpi, USB 2.0, 10/100/1000 Base-T/TX, IEEE 802.11 b/g/n, 2 GB, 44 dB, 69W
Quietly productive – rethink how a printer works for your office
The imagePROGRAF TM-300 is 60% quieter and can unobtrusively fit into any working environment. Even on plain paper, the full pigment Lucia TD ink system produces exceptional print quality, and continuous printing boosts output productivity.
Full pigment
High precision printing for CAD and posters from Canon’s unique 5-colour Lucia TD ink system.
Print faster
Boost productivity by printing faster, thanks to a 6-channel optimised 1.07-inch print head.
Quiet operation
Smoother cutting, reduced vibrations and dampened fans have decreased the running noise by 60%.
Compact design
Small footprint and front usability allows the imagePROGRAF TM-305 to fit flat to the wall.
Software suite
Direct Print & Share, PosterArtist Lite and Free Layout Plus support CAD and poster production.
| Printing |
|---|
| Print technology |
Thermal inkjet |
| Colour |
Yes |
| Maximum resolution |
2400 x 1200 DPI |
| Page description languages |
HP-GL/2, HP-RTL |
| Printing colours |
Black, Cyan, Magenta, Matte black, Yellow |
| Print head |
PF-06 |
| Paper handling |
|---|
| Maximum print size |
A0 (841 x 1189 mm) |
| ISO A-series sizes (A0...A9) |
A1, A2, A3, A3+ |
| Cut sheets |
Yes |
| Media thickness |
0.07 - 0.8 mm |
| Maximum roll length |
18 m |
| Maximum roll diameter |
15 cm |
| Borderless printing width |
36" |
| Media width (rolls) |
203.2 x 917 mm |
| Media width (sheets) |
203.2 x 917 mm |
| Roll paper |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| USB port |
Yes |
| USB connector |
USB Type-B |
| USB 2.0 ports quantity |
1 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| RJ-45 ports quantity |
1 |
| Performance |
|---|
| Product colour |
Black, White |
| Built-in display |
Yes |
| Display |
LCD |
| Display diagonal |
7.62 cm (3") |
| Control type |
Touch |
| Sound pressure level (printing) |
44 dB |
| RAM capacity |
2 GB |
| Certification |
CE, EAC, TUV, CB |
| Power |
|---|
| Power consumption (standby) |
3.6 W |
| Power consumption (off) |
0.3 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
15 - 30 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| System requirements |
|---|
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra |
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR |
| Weight & dimensions |
|---|
| Width |
1289 mm |
| Depth |
887 mm |
| Height |
1060 mm |
| Weight |
60 kg |
| Packaging data |
|---|
| Package width |
1462 mm |
| Package depth |
913 mm |
| Package height |
961 mm |
| Package weight |
105 kg |
| Manual |
Yes |
| Drivers included |
Yes |
| General |
|---|
| Product family |
imagePROGRAF |
| Other features |
|---|
| Touchscreen |
Yes |
| Logistics data |
|---|
| Harmonized System (HS) code |
84433210 |
