600dpi, CMOS CIS, RGB LED, 60ppm/120ipm, 80-sheets, USB 3.1, AC 100-240V, 285 x 180 x 178 mm
Robust, reliable, high-speed document scanner, offering impressive image quality and fast capture speeds.
Productivity-boosting, elegantly designed desktop scanner
The compact imageFORMULA DR-M260 has a small frame, yet produces a big performance. This dependable scanner is packed with innovative features and delivers outstanding image quality, with capture speeds of up to 60 ppm/120 ipm.
| Scanning |
|---|
| Maximum scan size |
216 x 5588 mm |
| Optical scanning resolution |
600 x 600 DPI |
| Colour scanning |
Yes |
| Duplex scanning |
Yes |
| Output colour depth |
24 bit |
| Output greyscale depth |
8 bit |
| Greyscale levels |
256 |
| ADF scan speed (b/w, A4) |
60 ppm |
| ADF scan speed (colour, A4) |
60 ppm |
| Duplex ADF scan speed (colour, A4) |
120 ipm |
| Duplex ADF scan speed (b/w, A4) |
120 ipm |
| Design |
|---|
| Scanner type |
Sheet-fed scanner |
| Built-in display |
Yes |
| Product colour |
Black |
| Display |
LCD |
| Performance |
|---|
| Sensor type |
CMOS CIS |
| Light source |
RGB LED |
| Scan file formats |
PDF |
| Daily duty cycle (max) |
7500 pages |
| Scan drivers |
ISIS, TWAIN |
| Input capacity |
|---|
| Standard input capacity |
80 sheets |
| Paper handling |
|---|
| Maximum ISO A-series paper size |
A4 |
| Scanning media types supported |
Business Card, Plastic Card, Post Card(JPN) |
| Media thickness (min) |
0.04 mm |
| Maximum scan width |
21.6 cm |
| Maximum scan length |
5.59 m |
| Ports & interfaces |
|---|
| USB port |
Yes |
| USB version |
3.2 Gen 2 (3.1 Gen 2) |
| Standard interfaces |
USB 3.2 Gen 1 (3.1 Gen 1) |
| Power |
|---|
| Power consumption (typical) |
23 W |
| Power supply type |
AC |
| Power consumption (standby) |
1.4 W |
| Power consumption (off) |
0.1 W |
| AC input frequency |
50 - 60 Hz |
| Input voltage |
100-240 V |
| General |
|---|
| Product family |
imageFORMULA |
| System requirements |
|---|
| Server operating systems supported |
Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016 |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Weight & dimensions |
|---|
| Width |
180 mm |
| Depth |
178 mm |
| Height |
285 mm |
| Weight |
3.6 kg |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Cables included |
AC, USB |
| Other features |
|---|
| Scan media weight |
27 - 413 g/m² |
| Logistics data |
|---|
| Harmonized System (HS) code |
84716070 |
