203 dpi, 6 ips, 64 MB SDRAM, 128 MB FlashROM, USB, Ethernet, Serial, Dark Grey
- Wristband Printer
- Order Label Printer
- Barcode Printer
Advanced Performance
- Printing speed up to 6 ips (152 mm/s)
- Fast data processing speed of various types of label
Smart Media Detection™
- Automatic paper detection such as gap media, black mark media and short length media paper
Dual interface
- Standard: Serial + USB
- Optional: Ethernet + WLAN* + USB
User-friendly Design
- Easy paper loading with adjustable paper guide
- Pause and cancel function-keys
Powerful Compatibility
The SLP-DX220 is fully compatible with market-leading programming language; SLCS, BPL-Z™, BPL-E™.
Label Artist™
Bixolon provides its custom label design program as bundle. It supports database connection as well as text, drawing lines and boxes, all kinds of graphics and 1D/2D Barcode printing.
| Printing |
|---|
| Maximum print length |
2 m |
| Minimum print length |
6 mm |
| Maximum printing width |
5.4 cm |
| Printing colours |
Black |
| Print speed |
152 mm/sec |
| Maximum resolution |
203 x 203 DPI |
| Colour |
No |
| Print technology |
Direct thermal |
| Paper handling |
|---|
| Maximum roll diameter |
13 cm |
| Media thickness |
0.06 - 0.2 mm |
| Supported paper width |
15 - 60 mm |
| Ports & interfaces |
|---|
| RS-232 ports |
1 |
| USB 2.0 ports quantity |
1 |
| USB port |
Yes |
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Connectivity technology |
Wired |
| Performance |
|---|
| Built-in barcodes |
1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, GS1 DataBar, IMB, Industrial 2/5, Interleaved 2/5, MicroPDF417, PDF417, POSTNET, QR Code, TLC39, UPC-A, UPC-E |
| Flash memory |
128 MB |
| Internal memory |
64 MB |
| Page description languages |
BPL |
| Design |
|---|
| Product colour |
Black |
| Power |
|---|
| AC input frequency |
50 - 60 Hz |
| AC input voltage |
100 - 240 V |
| Operational conditions |
|---|
| Operating temperature (T-T) |
10 - 80 °C |
| Storage temperature (T-T) |
10 - 90 °C |
| Storage relative humidity (H-H) |
-20 - 60% |
| Operating relative humidity (H-H) |
0 - 40% |
| Weight & dimensions |
|---|
| Weight |
1.36 kg |
| Height |
170 mm |
| Depth |
230 mm |
| Width |
120 mm |
| Logistics data |
|---|
| Harmonized System (HS) code |
84433210 |
| Technical details |
|---|
| Sustainability certificates |
ENERGY STAR |
| Other features |
|---|
| Navigation key |
Yes |
| LED indicators |
Yes |
