HDMI over IP Receiver (1080p@100m)
The ATEN VE8900R Video over IP Receiver delivers visually lossless 1080p AV signals with low latency over long distance via a local network of standard Gigabit network switch*.
The VE8900R provides an effective, easy-to-use, and economical digital signage solution with the following features and advantages that directly address the challenges system integrators encounter when implementing AV over IP systems:
Engineered to meet today’s demands of large scale, multi-display, 1080p signal transmission, and designed to be easy to set up and operate, the VE8900R Video over IP Receiver is an ideal product for a wide range of environments, such as trade shows, airports, university campuses, conference centers, and shopping centers
*Note: Regarding the detail information requirement of network switch, please refer to Implementation guide: assets.aten.com/product/manual/Implementation_Guide.pdf
| Features |
|---|
| Type |
AV receiver |
| Cable types supported |
Cat5e, Cat6 |
| Maximum transfer distance |
100 m |
| Audio system |
stereo |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Daisy chain |
Yes |
| Impedance |
100 Ω |
| Baud rate |
19.2 Kbit/s |
| Control type |
Buttons |
| Material |
Metal |
| HDCP |
Yes |
| Supported video modes |
1080p |
| LED indicators |
Yes |
| Product colour |
Black |
| Ports & interfaces |
|---|
| Connectivity technology |
Wired |
| RJ-45 input ports |
1 |
| Number of HDMI outputs |
1 |
| USB ports quantity |
2 |
| USB version |
2.0 |
| Video out |
1 |
| Remote (IR) output |
1 |
| Serial interface type |
RS-232 |
| Serial ports quantity |
1 |
| Audio output |
1 |
| DC-in jack |
Yes |
| Power |
|---|
| Power consumption (typical) |
4.28 W |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
0 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Width |
136 mm |
| Depth |
101 mm |
| Height |
29.6 mm |
| Weight |
490 g |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Manual |
Yes |
| Technical details |
|---|
| Compliance certificates |
RoHS |
