Screen size (inch) 23.8, Panel resolution 1920x1080, Max Refresh rate 100 Hz, Panel type IPS, HDMI HDMI 1.4 x 1, DisplayPort DisplayPort 1.2 x 1, D-SUB (VGA) 1x, DVI 0x, Sync technology (VRR) Adaptive Sync
24" FHD IPS monitor with essential features to get the most out of long working hours. Technologies including Adaptive Sync, Flicker-Free, Low Blue Light & full ergonomic features will support you while working and studying.
The AOC 24E3QAF offers all essentials for working or studying. This model mixes a great 24” IPS panel with wide viewing angle and FHD resolution, features for eye care such as Low Blue Mode and Flicker Free and built-in speakers to easily enjoy quality audio. For a neat workstation, this model also offers cable management. To ensure maximum comfort while working, 24E3QAF is fully ergonomic. Your productivity will be complemented with Adaptive Sync and 100Hz refresh rate to guarantee smooth and tear-free displaying performance, whether working with documents or watching content.
| Display |
|---|
| sRGB coverage (typical) |
104.1% |
| Surface hardness |
3H |
| DDC/CI |
Yes |
| High Dynamic Range (HDR) supported |
Yes |
| Local dimming |
Yes |
| Display diagonal (metric) |
60.5 cm |
| Digital vertical frequency |
48 - 75 Hz |
| Digital horizontal frequency |
30 - 85 kHz |
| Viewable size, vertical |
29.6 cm |
| Viewable size, horizontal |
52.7 cm |
| Vertical scan range |
48 - 75 Hz |
| Horizontal scan range |
30 - 85 kHz |
| Pixel density |
93 ppi |
| Pixel pitch |
0.2745 x 0.2745 mm |
| Display number of colours |
16.7 million colours |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Maximum refresh rate |
100 Hz |
| Contrast ratio (dynamic) |
20000000:1 |
| Contrast ratio (typical) |
1000:1 |
| Screen shape |
Flat |
| Anti-glare screen |
Yes |
| Response time measurement type |
GTG (Gray to Gray) |
| Response time |
4 ms |
| Backlight type |
W-LED |
| LED backlight |
Yes |
| Panel type |
IPS |
| HD type |
Full HD |
| Touchscreen |
No |
| Display technology |
LCD |
| Native aspect ratio |
16:9 |
| Display resolution |
1920 x 1080 pixels |
| Display diagonal |
60.5 cm (23.8") |
| Performance |
|---|
| Game mode |
Yes |
| Shadow сontrol |
Yes |
| Dial point |
Yes |
| FPS counter |
Yes |
| Low Blue Light technology |
Yes |
| Flicker-free technology |
Yes |
| VESA Adaptive Sync support |
Yes |
| Fast charging |
No |
| Multimedia |
|---|
| Built-in microphone |
No |
| RMS rated power |
4 W |
| Number of speakers |
2 |
| Built-in camera |
No |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Certification |
WEEE,REACH compliant,RoHs compliant,HF,CB,TUV-GS-Mark,ISO 9241-307,EAC,FCC |
| Feet colour |
Black |
| Detachable stand |
Yes |
| Front bezel colour |
Black |
| Frameless design |
Yes |
| Product colour |
Black |
| Market positioning |
Office |
| Ports & interfaces |
|---|
| Mobile High-Definition Link (MHL) |
No |
| AC (power) in |
Yes |
| HDCP version |
1.4 |
| HDCP |
Yes |
| Built-in KVM switch |
No |
| Headphone connectivity |
3.5 mm |
| Headphone outputs |
1 |
| Headphone out |
Yes |
| Audio input |
Yes |
| DisplayPort version |
1.2 |
| DisplayPorts quantity |
1 |
| HDMI version |
1.4 |
| HDMI ports quantity |
1 |
| HDMI |
Yes |
| DVI port |
No |
| VGA (D-Sub) ports quantity |
1 |
| Built-in USB hub |
No |
| Ergonomics |
|---|
| LED indicators |
Yes |
| Plug and Play |
Yes |
| Number of OSD languages |
16 |
| On Screen Display (OSD) languages |
Simplified Chinese, Traditional Chinese, Czech, Dutch, English, Finnish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish |
| On Screen Display (OSD) |
Yes |
| Tilt angle range |
-5 - 35° |
| Tilt adjustment |
Yes |
| Swivel angle range |
180 - 180° |
| Swivelling |
Yes |
| Pivot angle |
-90 - 90° |
| Pivot |
Yes |
| Adjustable height (max) |
15 cm |
| Height adjustment |
Yes |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Cable management |
Yes |
| Panel mounting interface |
100 x 100 mm |
| VESA mounting |
Yes |
| Power |
|---|
| Energy efficiency scale |
A to G |
| Power supply type |
Internal |
| Input current |
1.5 A |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Power consumption (off) |
0.3 W |
| Power consumption (max) |
35 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
13.79 W |
| Energy consumption (HDR) per 1000 hours |
18 kWh |
| Energy consumption (SDR) per 1000 hours |
18 kWh |
| Energy efficiency class (HDR) |
E |
| Energy efficiency class (SDR) |
E |
| Operational conditions |
|---|
| Non-operating altitude |
0 - 12192 m |
| Operating altitude |
0 - 5000 m |
| Storage relative humidity (H-H) |
5 - 93% |
| Operating relative humidity (H-H) |
10 - 85% |
| Storage temperature (T-T) |
-25 - 55 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Packaging content |
|---|
| Power cable length |
1.8 m |
| HDMI cable length |
1.8 m |
| DisplayPort cable length |
1.8 m |
| Quick start guide |
Yes |
| Cables included |
AC, HDMI, DisplayPort |
| Stand included |
Yes |
| Weight & dimensions |
|---|
| Weight (without stand) |
2.7 kg |
| Height (without stand) |
326.3 mm |
| Depth (without stand) |
50.7 mm |
| Width (without stand) |
540 mm |
| Weight (with stand) |
4.45 kg |
| Height (with stand) |
503.6 mm |
| Depth (with stand) |
200.1 mm |
| Width (with stand) |
540 mm |
| Packaging data |
|---|
| Package weight |
7.14 kg |
| Package height |
519 mm |
| Package depth |
162 mm |
| Package width |
613 mm |
| Sustainability |
|---|
| Sustainability certificates |
EPEAT Gold, TCO |
| Sustainability compliance |
Yes |
| General |
|---|
| Product family |
E3 |
| Recycling data |
|---|
| Post-consumer recycled plastic |
85% |
| Technical details |
|---|
| Warranty period |
3 year(s) |
| Compliance certificates |
CE |
| Other features |
|---|
| Light effects |
No |
| Mean time between failures (MTBF) |
30000 h |
| Recyclable packaging material |
100% |
| Bezel thickness type |
Frameless |
| Exterior finish type |
Textured |
| Compatibility |
VESA-P2 |
