16x 10/100M Base-T, Auto MDI/MDIX, 4K MAC table, 3.2Gbps
What It Does
The Tenda TEF1016D 16-Port 10/100 Switch is specially engineered to provide simple solution to expand SMB networks and campus networks at the best possible cost. Connect this 16-port switch to a router and add up to twenty three more computers or other Ethernet-based devices such as a printer, Network-Attached Storage (NAS), or Internet camera to increase the functionality of your network. Housed in sturdy metal case, it is ideal for years of dependable use.
Space-saving Design for Desktop & Rack Installation
100-Mbps speed, a switching capacity of up to 3.2Gbps and nonblocking wire speed forwarding meet the performance needs for a high speed and smooth network.
Standards & Protocols Compliance
Fully compliant with IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX.
Stable & Reliable Performance
The switch is a Plug-and-Play device that requires no configuration or software. Once you connect the hardware, the switch is operating! Each port is able to autosense half/full duplex mode and auto detect MDI/MDI-X crossover.
Inductive Lightning Protection
Integrating professional circuits, Tenda New 16-Port Unmanaged Fast Switch can protect the power supply from inducive lightning (6KV in Common Mode Protection).
Plug & Play
The switch is a Plug-and-Play device that requires no configuration or software. Once you connect the hardware, the switch is operating! Each port is able to autosense half/full duplex mode and auto detect MDI/MDI-X crossover.
| Management features |
|---|
| Switch type |
Unmanaged |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports quantity |
16 |
| Basic switching RJ-45 Ethernet ports type |
Fast Ethernet (10/100) |
| Network |
|---|
| Networking standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| 10G support |
No |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX |
| Cable types supported |
Cat3, Cat5 |
| Full duplex |
Yes |
| MAC address auto-learning supported |
Yes |
| Auto-negotiation |
Yes |
| Auto MDI/MDI-X |
Yes |
| Data transmission |
|---|
| MAC address table |
4000 entries |
| Switching capacity |
3.2 Gbit/s |
| Forwarding rate |
0.1488 Mpps |
| Store-and-forward |
Yes |
| Packet forwarding rate (10 Mbps) |
14880 pps |
| Packet forwarding rate (100 Mbps) |
148800 pps |
| Security |
|---|
| Access Control List (ACL) |
Yes |
| Design |
|---|
| Rack mounting |
Yes |
| Stackable |
Yes |
| Product colour |
Grey |
| Certification |
CE, FCC, RoHS |
| Performance |
|---|
| Plug and Play |
Yes |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Power consumption (typical) |
20 W |
| Surge protection |
Yes |
| Surge protection voltage |
6 kV |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) |
No |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
|---|
| Width |
122 mm |
| Depth |
441 mm |
| Height |
44 mm |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
