8x 10/100/1000Mbps, IEEE 802.3/u/x/ab, 100 - 240V, 50/60Hz
SG108 is a 8-Port Gigabit Desktop SOHO switch. It provides 8 10/100/1000Mbps auto-negotiation ports, which you can use to establish a LAN network, or extend the uplink network. Compared with a 100M switch, it enhances transmission speed up to 10 times, eliminating the bottleneck of cascading bandwidth. It supports desktop installation and wall-mounting. Without configuration, it can be played once plugged.
With the stable connectivity and easy-to-use features, it is perfectly fit for the networking of school dormitories, small offices, home offices and Video Surveillance.
- 8x 10/100/1000Mbps auto-negotiation ports
- Auto MDI/MDIX simplifies networking and maintenance
- Full wire speed forwarding ensures a smooth network experience
- Flow control for full duplex and backpressure for half duplex avoids frame dropping as port blocked
- Adopts store-and-forward mechanism and provides 4K MAC address table
- 9K Jumbo frame improves the forwarding speed of large data
- Adopts green and environmental ABS material, improving heat resistance and heat dissipation
- Allows IP camera accessing and provides a running and clear image
- Desktop and wall mounting simplify installation
| Management features |
|---|
| Switch type |
Unmanaged |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Power connector |
DC-in jack |
| Network |
|---|
| Networking standards |
IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| 10G support |
No |
| Data transmission |
|---|
| MAC address table |
4000 entries |
| Switching capacity |
16 Gbit/s |
| Design |
|---|
| Rack mounting |
No |
| Product colour |
Black |
| Power |
|---|
| Power supply included |
Yes |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Output voltage |
9 V |
| Output current |
0.6 A |
| Power consumption (max) |
5.5 W |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) |
No |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 45 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
|---|
| Width |
142 mm |
| Depth |
90 mm |
| Height |
24 mm |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
