IT7-PCS 4MP PoE Full-Color Bullet Security Camera
4MP PoE Full-Color Bullet Security Camera IT7-PCS is a high-performance 4MP (2560*1440) engineering camera that integrates such functions as full-color night vision, human detection, motion detection alarm, remote audio pickup and PoE power supply. It is commonly used in such indoor and outdoor monitoring scenarios as parking lots, shops, supermarkets, and jewelry stores. The camera can be used with NVR, and also supports smartphone app remote control.
4MP PoE Full-Color Version
Critical image stored in full color with smart night vision function
The camera provides the human/motion detection function. When the image changes, the full-color night vision mode will be enabled automatically. The three modes of infrared, full-color and smart full-color can be switched freely to meet various night monitoring requirements.
Installation simplified with a standard PoE power supply
The network power supply of the camera can be realized with only one Ethernet cable that improving the efficiency of project installation. The standard PoE protocol has strong compatibility and is safer to use.
4MP HD image with more details even when zoomed
Equipped with 4MP high-performance CMOS image sensor, the camera provides a resolution up to 2560 x 1440. It adopts the 3D digital noise reduction technology to filter the noise of the image, the smart WDR technology to adjust the brightness, and the smart anti-overexposure technology to suppress the strong light.
Audio and video synched with remote audio pickup
With an inbuilt highly sensitive microphone that supports remote audio pickup, the camera can sync audio and video to truly restore the scene.
Precise human detection, white light used to deter intruders
App remote control is supported. When the device detects abnormal conditions, the alarm notification will be pushed to the TDSEE app, and white light is used to deter intruders.
Storage and bandwidth halved with H.265+ coding technology
Compared with H.265, the new-generation H.265+ coding technology saves 50% storage space, which further smoothes the videos and saves the data storage space.
IP67 waterproof and dustproof
As the operating temperature is -20℃ to 60℃, the camera can effectively resist the high and low temperature. With IP67 waterproof and dustproof design, the camera can withstand rainy, sunny, stormy, and even snowy weather.
High compatibility with ONVIF supported
It can be used with mainstream NVRs in the market, featuring high compatibility.
| Performance |
|---|
| Type |
IP security camera |
| Placement supported |
Outdoor |
| Connectivity technology |
Wired |
| Certification |
CE
RoHs
FCC |
| Design |
|---|
| Form factor |
Bullet |
| Mounting type |
Ceiling/wall |
| Product colour |
Black, White |
| International Protection (IP) code |
IP67 |
| Weatherproof |
Yes |
| Image sensor |
|---|
| Sensor type |
CMOS |
| Lens system |
|---|
| Number of lenses |
1 |
| Lens diameter |
4 mm |
| Maximum aperture number |
2.2 |
| Night vision |
|---|
| Night vision |
Yes |
| Night vision distance |
30 m |
| LED type |
IR |
| Video |
|---|
| Maximum resolution |
2560 x 1440 pixels |
| Total megapixels |
4 MP |
| Video formats supported |
H.264, H.265, H.265+ |
| Noise reduction |
Yes |
| Noise reduction technology |
3D noise reduction |
| Region of Interest (ROI) encoding |
Yes |
| Digital Wide Dynamic Range (DWDR) |
Yes |
| Back Light Compensation (BLC) |
Yes |
| Audio |
|---|
| Built-in microphone |
Yes |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Bluetooth |
No |
| Supported network protocols |
RTSP, HTTP, DHCP, DDNS, ONVIF |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
|---|
| Power source type |
PoE |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-20 - 60 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 95% |
| Storage relative humidity (H-H) |
3 - 95% |
| Weight & dimensions |
|---|
| Width |
85 mm |
| Depth |
166 mm |
| Height |
85 mm |
| Packaging content |
|---|
| Number of cameras |
1 |
| Manual |
Yes |
| Waterproof connector |
Yes |
| Packaging content |
Security Camera, Quick installation guide，Waterproof kit，General Public license notice |
