Intel SKU BX8071514700

Intel Core i7-14700 processor 33 MB Smart Cache Box

R 8,074.66Incl. VAT

In stock

Delivery Nationwide delivery. Cost and time shown at checkout.
Returns 7-day returns on unopened items. Refund policy

Overview

Boxed Intel Core i7 processor 14700 (33M Cache, up to 5.40 GHz) FC-LGA16A
Intel Core i7 14700 Up to 5.4 GHZ; 20 Cores (8P+12E); 28 Thread; 33MB Smartcache; 65W TDP; Intel® Laminar RM1 Cooler included;
Processor
Processor manufacturer Intel
Processor family Intel® Core™ i7
Processor generation Intel® Core™ i7 (14th gen)
Processor model i7-14700
Processor cores 20
Processor socket LGA 1700
Cooler included Yes
Processor threads 28
Processor operating modes 64-bit
Performance cores 8
Efficient cores 12
Processor boost frequency 5.4 GHz
Performance-core boost frequency 5.3 GHz
Performance-core base frequency 2.1 GHz
Efficient-core boost frequency 4.2 GHz
Efficient-core base frequency 1.5 GHz
Processor cache 33 MB
Processor cache type Smart Cache
Maximum turbo power 219 W
Processor base power 65 W
Stepping B0
Maximum number of DMI lanes 8
Memory bandwidth supported by processor (max) 89.6 GB/s
Processor codename Raptor Lake
Processor ARK ID 236781
Memory
Maximum internal memory supported by processor 192 GB
Memory types supported by processor DDR4-SDRAM, DDR5-SDRAM
Memory channels Dual-channel
ECC Yes
Memory bandwidth (max) 89.6 GB/s
Graphics
Discrete graphics card No
On-board graphics card Yes
On-board graphics card model Intel UHD Graphics 770
On-board graphics card outputs supported Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card dynamic frequency (max) 1600 MHz
On-board graphics card base frequency 300 MHz
Number of displays supported (on-board graphics) 4
On-board graphics card OpenGL version 4.5
On-board graphics card DirectX version 12.0
On-board graphics card maximum resolution (HDMI) 4096 x 2160 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel) 5120 x 3200 pixels
On-board graphics card maximum resolution (DisplayPort) 7680 x 4320 pixels
On-board graphics card refresh rate at maximum resolution (HDMI) 60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) 120 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort) 60 Hz
On-board graphics card ID 0xA780
Discrete graphics card model Not available
Number of execution units 32
Multi-Format Codec Engines 2
Features
Thermal Monitoring Technologies Yes
Idle States Yes
Execute Disable Bit Yes
Market segment Desktop
Use conditions Workstation, PC/Client/Tablet
Maximum number of PCI Express lanes 20
PCI Express slots version 4.0, 5.0
PCI Express configurations 1x16+1x4, 2x8+1x4
Supported instruction sets AVX 2.0, SSE4.1, SSE4.2
Direct Media Interface (DMI) Revision 4.0
CPU configuration (max) 1
Embedded options available Yes
Scalability 1S
Export Control Classification Number (ECCN) 5A992C
Commodity Classification Automated Tracking System (CCATS) 740.17B1
Processor special features
Intel® Clear Video HD Technology (Intel® CVT HD) Yes
Intel® Quick Sync Video Technology Yes
Intel® Speed Shift Technology Yes
Enhanced Intel SpeedStep Technology Yes
Intel® AES New Instructions (Intel® AES-NI) Yes
Intel® Turbo Boost Technology 2.0
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Intel® Turbo Boost Max Technology 3.0 frequency 5.4 GHz
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Yes
Intel® Control-flow Enforcement Technology (CET) Yes
Intel® Thread Director Yes
Intel® Standard Manageability (ISM) Yes
Intel® Secure Key Yes
Intel® Boot Guard Yes
Intel® OS Guard Yes
Mode-based Execute Control (MBE) Yes
Intel® Volume Management Device (VMD) Yes
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel Turbo Boost Max Technology 3.0 Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel Virtualization Technology (VT-x) Yes
Intel 64 Yes
Intel VT-x with Extended Page Tables (EPT) Yes
General
Product series i7
Product family Core
Operational conditions
Tjunction 100 °C
Packaging data
Package type Box
Technical details
OpenCL version 3.0
Status Launched
Launch date Q1'24
Logistics data
Harmonized System (HS) code 8542310001
Weight & dimensions
Processor package size 45 x 37.5 mm
Other features
L2 cache 28672 KB
Maximum internal memory 192 GB
Graphics output eDP 1.4b, DP 1.4a, HDMI 2.1

Specifications

BrandIntel
TypeProcessors
SKUBX8071514700
Barcode0735858547673,5032037279239,735858547673
