2 MP, CMOS, 2.8mm, 1920x1080, WDR, 2D DNR, 12V DC, 84.6x78.9 mm
| Performance |
| Type |
CCTV security camera |
| Placement supported |
Indoor |
| Connectivity technology |
Wired |
| Wide Dynamic Range (WDR) |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Day/night mode |
Yes |
| Languages support |
English |
| Number of languages |
1 |
| Design |
| Form factor |
Turret |
| Mounting type |
Ceiling/wall |
| Product colour |
White |
| Housing material |
Plastic |
| Camera |
| Minimum illumination |
0 lx |
| Angle of rotation |
360° |
| Lens viewing angle, horizontal |
102° |
| Lens viewing angle, vertical |
55° |
| Lens viewing angle, diagonal |
123° |
| Tilt angle range |
0 - 75° |
| Pan range |
0 - 360° |
| Camera shutter speed |
1/25 - 1/50000; 1/30 - 1/50000 s |
| Image sensor |
| Sensor type |
CMOS |
| Number of sensors |
1 |
| Lens system |
| Number of lenses |
1 |
| Fixed focal length |
2.8 mm |
| Night vision |
| Night vision |
Yes |
| Night vision distance |
20 m |
| LED type |
IR |
| Video |
| Maximum resolution |
1920 x 1080 pixels |
| Total megapixels |
2 MP |
| Frame rate |
30 fps |
| Analog signal format system |
NTSC, PAL |
| Noise reduction |
Yes |
| Noise reduction technology |
2D noise reduction |
| Gain control type |
Auto |
| Digital Wide Dynamic Range (DWDR) |
Yes |
| Back Light Compensation (BLC) |
Yes |
| Image quality adjustment |
Brightness, Mirror, Sharpness |
| Network |
| Ethernet LAN |
No |
| Wi-Fi |
No |
| Bluetooth |
No |
| Power |
| Power source type |
DC |
| Power consumption (max) |
3.3 W |
| DC output voltage |
12 |
| Operational conditions |
| Operating temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
0 - 90% |
| Weight & dimensions |
| Height |
78.9 mm |
| Diameter |
8.46 cm |
| Weight |
195 g |
| Packaging content |
| Number of cameras |
1 |
