Hikvision DS-6916UDI video decoder 16 channels 3840 x 2160 pixels
Only 2 left
Overview
DS-6901UDI provides HDMI, VGA, and BNC output interfaces.
Up to 4K (3840 × 2160@30Hz) via HDMI output interfaces (only for even interface).
H.265+/H.265, H.264+/H.264, MPEG4 and MJPEG video compression.
Three encoding levels: baseline, main, and high-profile.
G.722, G711A, G726, G711U, MPEG2-L2, and AAC audio compression.
| Performance | |
|---|---|
| Channels quantity | 16 channels |
| Alarm input channels | 8 |
| Alarm output channels | 8 |
| Maximum video resolution | 3840 x 2160 pixels |
| Maximum frame rate | 30 fps |
| Supported graphics resolutions | 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 960, 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 3840 x 2160 |
| Supported video modes | 720p, 1080p |
| PTZ control | Yes |
| Live view | Yes |
| Video formats supported | H.264, H.264+, H.265, H.265+, M-JPEG, MPEG4 |
| Audio formats supported | AAC |
| Features | |
|---|---|
| Product colour | Black |
| LED indicators | Yes |
| Network | |
|---|---|
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000BaseE-T(X) |
| Ports & interfaces | |
|---|---|
| Number of HDMI outputs | 16 |
| DVI output ports | 1 |
| VGA (D-Sub) output ports | 1 |
| BNC output ports | 8 |
| Ethernet LAN (RJ-45) ports | 18 |
| RS-232 ports | 1 |
| RS-485 ports | 1 |
| Power | |
|---|---|
| AC adapter input voltage | 100 - 240 V |
| Power consumption (max) | 108 W |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
|---|---|
| Width | 440 mm |
| Depth | 311 mm |
| Height | 80 mm |
| Weight | 6.4 kg |
Specifications
| Brand | Hikvision Digital Technology |
|---|---|
| Type | Video Decoders |
| SKU | DS-6916UDI |
| Barcode | 0842571103496,6954273635114 |
