Epson ELPDC07
Only 1 left
Overview
Portable visualiser
Let a wide audience get up close to your source material with the Epson ELPDC07 visualiser. Delivering high-quality images, this portable and adaptable camera sets up quickly and can be connected directly to the latest Epson projectors.
See in great detail
Share high-quality visuals including detailed diagrams and textbook pages with a Full HD 1080p output and 8x digital zoom. You can even adjust the height and rotate the camera 90º to accommodate 3D objects.
Effortless to use
Minimise preparation time with this high-tech, compact and affordable portable solution, that makes it quick and easy to enlarge source material. In just seconds, you can connect directly to the latest Epson projectors using the two in one USB cable connection which provides power and transmits the video signal.
Highly portable, modern design
The Epson ELPDC07 visualiser is neat and compact, it features LED illumination, a built-in microphone and doesn’t need a separate power supply. It’s also light and easy to carry in the included carry case, with the arm folding neatly down into the base. Needing just 2.5W, you can be sure that its power consumption meets modern energy conservation requirements .
| Camera | |
|---|---|
| Effective sensor resolution | 2 MP |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Sensor type | CMOS |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Maximum frame rate | 30 fps |
| Image freeze | Yes |
| Light source | LED |
| Lens system | |
|---|---|
| Auto focus | Yes |
| Optical zoom | 8x |
| Digital zoom | 8x |
| Shooting area (WxD) | 297 x 420 mm |
| Ports & interfaces | |
|---|---|
| Interface | USB 2.0 |
| USB connector type | USB Type-B |
| Technical details | |
|---|---|
| Product colour | White |
| Display modes | Microscope |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Security features | Kensington lock |
| Zoom capability | Yes |
| Special features | Auto focus, Freeze |
| Country of origin | Philippines |
| Image quality adjustment | Brightness |
| Illumination | Yes |
| Bundled software | Easy Interactive Tools, TWAIN driver for Epson Document Camera (for Windows) |
| Power consumption | 2.5 Watt |
| Box contents | Carrying Case, Information sheet, USB cable, Warranty document |
| Power | |
|---|---|
| Power supply type | USB |
| Power consumption (typical) | 2.5 W |
| Power consumption (standby) | 2.5 W |
| Weight & dimensions | |
|---|---|
| Width | 260 mm |
| Depth | 60 mm |
| Height | 76 mm |
| Weight | 1 kg |
| Dimensions folded (WxDxH) | 260 x 60 x 76 mm |
| Packaging data | |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 195 mm |
| Package depth | 320 mm |
| Package height | 120 mm |
| Package weight | 1.73 kg |
| Packaging content | |
|---|---|
| Warranty card | Yes |
| Cables included | USB |
| Carrying case | Yes |
Specifications
| Brand | Epson |
|---|---|
| Type | Document Cameras |
| SKU | V12H759040 |
| Barcode | 8715946616292 |
