Intel Xeon Silver 4314 Processor (24MB Cache, up to 3.4 GHz)
The Intel Xeon® Silver 4314 2.4GHz Sixteen Core Processor enhances the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced SpeedStep® technology that allows tradeoffs to be made between performance and power consumption.
Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the Xeon Silver 4314 2.4GHz Sixteen Core Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.
| Processor |
|---|
| Processor manufacturer |
Intel |
| Processor family |
Intel Xeon Silver |
| Processor generation |
3rd Generation Intel® Xeon® Scalable |
| Processor model |
4314 |
| Processor base frequency |
2.4 GHz |
| Processor cores |
16 |
| Processor socket |
LGA 4189 |
| Processor lithography |
10 nm |
| Cooler included |
No |
| Component for |
Server/workstation |
| Processor threads |
32 |
| System bus rate |
10.4 GT/s |
| Processor operating modes |
64-bit |
| Processor boost frequency |
3.4 GHz |
| Processor cache |
24 MB |
| Thermal Design Power (TDP) |
135 W |
| Processor codename |
Ice Lake |
| Processor ARK ID |
215269 |
| Memory |
|---|
| Maximum internal memory supported by processor |
6 TB |
| Memory types supported by processor |
DDR4-SDRAM |
| Memory clock speeds supported by processor |
2667 MHz |
| Memory channels |
Octa-channel |
| ECC |
Yes |
| Graphics |
|---|
| Discrete graphics card |
No |
| On-board graphics card |
No |
| On-board graphics card model |
Not available |
| Discrete graphics card model |
Not available |
| Features |
|---|
| Execute Disable Bit |
Yes |
| Market segment |
Server |
| Maximum number of PCI Express lanes |
64 |
| PCI Express slots version |
4.0 |
| Supported instruction sets |
SSE4.2, AVX, AVX 2.0, AVX-512 |
| Embedded options available |
Yes |
| Scalability |
2S |
| Export Control Classification Number (ECCN) |
5A992CN3 |
| Commodity Classification Automated Tracking System (CCATS) |
G178966 |
| Processor special features |
|---|
| Intel® Speed Shift Technology |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® Transactional Synchronization Extensions |
Yes |
| Intel® Total Memory Encryption |
Yes |
| Maximum Enclave Size Support for Intel® SGX |
8 GB |
| Intel® Platform Firmware Resilience Support |
Yes |
| Intel® Crypto Acceleration |
Yes |
| Mode-based Execute Control (MBE) |
Yes |
| Intel® Resource Director Technology (Intel® RDT) |
Yes |
| Intel Software Guard Extensions (Intel SGX) |
Yes |
| Intel® Optane™ DC Persistent Memory Supported |
Yes |
| Intel® Volume Management Device (VMD) |
Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) |
Yes |
| AVX-512 Fused Multiply-Add (FMA) units |
2 |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel 64 |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| General |
|---|
| Product family |
Xeon |
| Operational conditions |
|---|
| Tcase |
86 °C |
| Technical details |
|---|
| Supported memory types |
DDR4-SDRAM |
| Number of UPI links |
2 |
| Memory speed (max) |
2667 MHz |
| Status |
Launched |
| Launch date |
Q2'21 |
| Logistics data |
|---|
| Harmonized System (HS) code |
85423119 |
| Weight & dimensions |
|---|
| Processor package size |
77.5 x 56.5 mm |
| Other features |
|---|
| Maximum internal memory |
6 TB |
