D-Link 10GBASE SFP+ (DDM) network transceiver module Fiber optic 10000 Mbit/s SFP+ 850 nm

R 2,926.08
R 2,926.08
R 2,926.08
Shipping calculated at checkout.

Want next day delivery? Be quick!

I18n Error: Missing interpolation value "end_date" for "Ends on {{ end_date }}"
Low stock! Only 2 left
10GBASE SFP+ (DDM) - 850nm Multi-Mode, 300m

The D-Link 10GBASE SFP+ Transceivers offer customers a wide variety of 10Gbps Ethernet connectivity option for data center, enterprise wiring closet, and service provider transport applications. Compared with existing 10G XFP, 10G SFP+ is with smaller form factor, with lower cost, lower power dissipation, and allows higher port density.

The DEM-431XT-DD is a 10GBASE-SR high performance 850nm multimode SFP+ transceiver with Digital Diagnostics Monitoring (DDM) support. It supports full duplex, 10Gigabit speeds on Multi-Mode fiber for distances of up to 33m/300m on 62.5µm/50µm fiber respectively. DDM allows Real time monitoring of critical device parameters including: bias current, transmit & receive power, temperature, and voltage. The DEM-431XT-DD is hot pluggable and is backed by a standard 2-year product warranty and free technical support.

Performance
Networking standards IEEE 802.3ae
Rx power (max) 0.5 dBmW
Rx power (min) -11.1 dBmW
Tx power (max) -1 dBmW
Tx power (min) -5 dBmW
Wavelength 850 nm
Maximum transfer distance 300 m
SFP transceiver standard SR
Fiber cable diameters supported (core/cladding) 50/125,62.5/125 µm
Fiber optic connector LC
Multi-mode fiber (MMF) supported Yes
Interface type SFP+
Maximum data transfer rate 10000 Mbit/s
SFP transceiver type Fiber optic
Features
Certification CE, FCC, VCCI, C-Tick
Safety UL, TUV, CDRH
Hot-swap Yes
Plug and Play Yes
Power
Input voltage 3.3 V
Operational conditions
Storage relative humidity (H-H) 0 - 85%
Operating relative humidity (H-H) 0 - 85%
Storage temperature (T-T) -40 - 85 °C
Operating temperature (T-T) 0 - 70 °C
Weight & dimensions
Weight 22 g
Height 56.5 mm
Depth 11.8 mm
Width 14.8 mm
Technical details
Compliance certificates RoHS
