DLP, OSRAM 240W E30 lamp.1, 1280 x 800, 4000 lm, HDMI1.4b (HDCP 1.4) x 2
The Classroom Projector Family
The short-throw projectors making big pictures at small distances.
Short-throw Projection
Short-throw projectors create better images at shorter distances, perfect for a busy classroom with little space.
Damage Prevention
Dust and projectors are not friends. A sealed engined projector can defend against the detrimental effects of dust.
Keystone Correction
Keystoning corrects your projection to fix image distortion caused by incorrect projector positioning.
LAN Network Projection
Compliant with Crestron® Network System to enable easier control of your projector.
| Projector |
|---|
| Projector brightness |
4000 ANSI lumens |
| Projection technology |
DLP |
| Projector native resolution |
WXGA (1280x800) |
| Contrast ratio (typical) |
20000:1 |
| Native aspect ratio |
16:9 |
| Supported aspect ratios |
4:3, 16:9, 16:10 |
| Screen size compatibility |
812.8 - 7620 mm (32 - 300") |
| Projector brightness (economic mode) |
3200 ANSI lumens |
| Horizontal scan range |
15 - 100 kHz |
| Vertical scan range |
24 - 120 Hz |
| Light source |
|---|
| Light source type |
Lamp |
| Lamp power |
240 W |
| Lens system |
|---|
| Focus |
Manual |
| Aperture range (F-F) |
2.8 - 7.51 |
| Zoom capability |
Yes |
| Offset |
125% |
| Video |
|---|
| Full HD |
Yes |
| Supported graphics resolutions |
1280 x 800 (WXGA), 1920 x 1200 (WUXGA) |
| Ports & interfaces |
|---|
| VGA (D-Sub) ports quantity |
2 |
| HDMI ports quantity |
2 |
| HDMI connector type |
Full-size |
| HDMI version |
1.4b |
| Component video (YPbPr/YCbCr) in |
1 |
| USB 2.0 Type-A ports quantity |
1 |
| Audio (L/R) in |
1 |
| Audio (L/R) out |
1 |
| Serial interface type |
RS-232 |
| AC (power) in |
Yes |
| Storage |
|---|
| Card reader integrated |
No |
| Features |
|---|
| HDCP |
Yes |
| Projection modes |
Ceiling, Front, Rear |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
1 |
| RMS rated power |
16 W |
| Design |
|---|
| Product type |
Standard throw projector |
| Market positioning |
Education |
| Product colour |
White |
| Placement |
Ceiling |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| Power source |
AC |
| Power consumption (typical) |
285 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (economy mode) |
210 W |
| AC input voltage |
100 - 240 V |
| General |
|---|
| Product family |
Professional and Education |
| Weight & dimensions |
|---|
| Weight |
3.1 kg |
| Width |
313 mm |
| Depth |
236 mm |
| Height |
113.7 mm |
| Packaging content |
|---|
| Remote control included |
Yes |
| Batteries included |
Yes |
| Cables included |
AC, VGA |
